Becker S60II - Connection Plan; Technical Data

15
DE
GB
FR
NL
1 2 3 + 5 6 7 8 9
1 2 3 - 5 6 7 8 9
R
R
5
A
B
gn/ge
1 2 3 4 5 6 7 8 9 10 11
12
1-channel radio slot
3 2 1
11 8 9
7 6 5
OPEN
CLOSED
+UB
Contactor
PE
PE
PE
Mains
L3 L2 L1 N
Transformer
Relay
NO C N
C
Entry door/
spring fracture
UP
DOWN
STOP
Slack cable limit switch Emergency stop switch
Ext. triple
pushbutton
STOP-UP
Pneumatic switching
rail (DW)
or
Electrical switching
rail (EL)
IMP / UP-STOP-DOWN-STOP
LS / Light barrier
WZL / Automatic reclosi
ng feature
max 10A CEE 16A
Potential-free relay
output
Multicard insert car
d
or deadman’s insert c
ard
F1 400 mA
T
F2 200 mA
T
Drive with mechanical limit switching
24V
UP
STOP
DOWN
STOP-A
UF
USA
IMP
LS
WZL
NOT-A
US
E
E
Motor
W V U
FS1
A
B
Triple
pushbutton
SF4
SF3
SF1
SF2
SF5 SF6 SF7 SF8
S1F Safety limit switch OPEN
S2F Safety limit switch CLOSED
S3F Safety limit switch emergency activation
S4F Thermal switch
S5 Operating limit switch OPEN
S6 Operating limit switch CLOSED
S7 Testing pre-limit switch
S8 Special function limit switch 1/2 door height
LED OPEN Display for ascent
LED CLOSED Display for descent
LED +UB Display for operating voltage
FS1=A Relay actuation by Mutlicard II
FS1=B Relay actuation by limit switch S8
A1/B1 UP command
A1/B2 DOWN command, external triple pushbutton
A2/B2 STOP command
A3/B3 Emergency stop switch
A4/B4 Voltage output 24V DC / 200 mA
A5/B5 STOP-UP / Run-in safety device
A6/B6 USA / Closing edge safety device
A7/B7 IMP / Switch for step switching sequence
A8/B8 LS / Light barrier
A9/B9 WZL / Switch for automatic reclosing
F1-400mA T Fuse for control electrics
F2-200mA T Fuse for 24V output voltage
(A4/B4)
Type: S60 II
Power supply: 3 x 400/230V 50/60 Hz (L1, L2, L3, N, PE)
Max. rated power of motor:
1.8 KW
Weight: 1.5 kg
Dimensions: 182 x 254 x 90 (W x H x D)
Class of protection: IP 54 (IP 65 optional)
For indoor installation only
Connection plan
Technical data
