Parameterization and commissioning
BK11x0, BK1250 67Version: 4.1
Index 4012 Coupler Table 9 [LO]: Configuration of the Bus Terminal block
Index (hex) Name Meaning Flags Default
4012:0 Coupler Table 9 [LO] Length of this object RO max. 128
4012:01 Subindex 001 Register 0: Name of the Bus Coupler RO 0x0460 (1120
dec
1
)
4012:02 Subindex 002 Register 1: Name of the first terminal RO e.g.: 0x8201
(33281
dec
2
)
4012:03 Subindex 003 Register 2: Name of the 2
nd
terminal RO e.g.: 0x0BBA
(3002
dec
1
)
4012:04 Subindex 004 Register 3: Name of the 3
rd
terminal RO e.g.: 0x0C84 (3204
dec
1
)
4012:80 Subindex 128 Register 127: Name of the 127
th
terminal RO
1
) For Bus Coupler and intelligent (e.g. analog) terminals, the terminal designation is
specified decimally in plain text; e.g. 0x0C84 (3204
dec
) means KL3204.
2
) For simple (digital) terminals, the following coding applies:
Bit Value Meaning
15 0
bin
intelligent (e.g. analog) terminal
1
bin
simple (digital) terminal
14...8 xxxxxx
bin
terminal size in bit (range of values: 0 to 63 bit)
7 1
bin
Shift register extension for Control Panels
6...3 0
bin
reserved
2 1
bin
KL1212
1 1
bin
Output terminal Special case: 00
bin
means KL1202 or KL2212 (digital termi-
nals with input and output data)
0 1
bin
Input terminal
Index 4013 Coupler Table 9 [HI]: Configuration of the Bus Terminal block (continuation if more than
127 terminals)
Index (hex) Name Meaning Flags Default
4013:0 Coupler Table 9 [HI] Length of this object RO max. 128
dec
4013:01 Subindex 001 Register 128: Name of the 128
th
terminal RO
4013:02 Subindex 002 Register 129: Name of the 129
th
terminal RO
4013:04 Subindex 128 Register 255: Name of the 255
th
terminal RO
Index 40B4 Coupler Table 90 [LO]: Internal diagnostic information for the Bus Coupler
Index (hex) Name Meaning Flags Default
40B4:0 Coupler Table 90 [LO] Length of this object RO 128
dec
40B4:01 Subindex 001 Register 0: reserved RO
40B4:02 Subindex 002 Register 1: reserved RO
40B4:04 Subindex 128 Register 127: reserved RO
Index 40B5 Coupler Table 90 [HI]: Internal diagnostic information for the Bus Coupler (cont.)
Index (hex) Name Meaning Flags Default
40B5:0 Coupler Table 90 [HI] Length of this object RO 128
dec
40B5:01 Subindex 001 Register 128: reserved RO
40B5:02 Subindex 002 Register 129: reserved RO
40B5:04 Subindex 128 Register 255: reserved RO
Index 40C4 Coupler Table 98 [LO]: Pd Update time (µs)
Index (hex) Name Meaning Flags Default
40C4:0 Coupler Table 98 Pd
Update time (µs)
Length of this object RW 5
40C4:01 Min time minimum update time on the K-bus RW 0x0355 (853
dec
)
40C4:02 Max time maximum update time on the K-bus RW 0x059A (1434
dec
)
40C4:03 Curr time current update time on the K-bus RW 0x036A (874
dec
)
40C4:04 - reserved RW 0x0000 (0
dec
)
40C4:50 - reserved RW 0x09F8 (2552
dec
)
