Beckhoff BK1120 User Manual

Parameterization and commissioning
BK11x0, BK125068 Version: 4.1
Index 40C5 Coupler Table 98 [HI]: Pd update time (µs) (cont.)
Index (hex) Name Meaning Flags Default
40C5:0 Coupler Table 98 Pd
Update time (µs)
Length of this object RW 0
Index 40C8 Coupler Table 100 [LO]: Reserved for internal fieldbus-specific settings
Index (hex) Name Meaning Flags Default
40C8:0 Coupler Table 100
[LO]
Length of this object RO 128
dec
40C8:01 Subindex 001 Register 0: reserved RO
40C8:02 Subindex 002 Register 1: reserved RO
40C8:04 Subindex 128 Register 127: reserved RO
Index 40C9 Coupler Table 100 [HI]: Reserved for internal fieldbus-specific settings (cont.)
Index (hex) Name Meaning Flags Default
40C9:0 Coupler Table 100 [HI] Length of this object RO 128
dec
40C9:01 Subindex 001 Register 128: reserved RO
40C9:02 Subindex 002 Register 129: reserved RO
40C9:04 Subindex 128 Register 255: reserved RO
Index 40FE Coupler Table 127 [LO]: Reserved for internal settings
Index (hex) Name Meaning Flags Default
40FE:0 Coupler Table 100
[LO]
Length of this object RO 128
dec
40FE:01 Subindex 001 Register 0: reserved RO
40FE:02 Subindex 002 Register 1: reserved RO
40FE:04 Subindex 128 Register 127: reserved RO
Index 40FF Coupler Table 127 [HI]: Reserved for internal settings (cont.)
Index (hex) Name Meaning Flags Default
40FF:0 Coupler Table 100 [HI] Length of this object RO 128
dec
40FF:01 Subindex 001 Register 128: reserved RO
40FF:02 Subindex 002 Register 129: reserved RO
40FF:04 Subindex 128 Register 255: reserved RO
Index 427F Terminal No
Index (hex) Name Meaning Flags Default
427F:0 Terminal No Number of the terminal in the Bus Terminal block,
which can be parameterized with the following four ta-
bles (object 4280 - 4287).
Counting method: the Bus Coupler is no. 0 in the Bus
Terminal block. The first terminal connected to the Bus
Coupler is no.1 etc.
Only intelligent terminals (with register set) can be pa-
rameterized!
RO 3
Index 4280 Terminal Table 0 [LO]: for parameterization of the terminal specified with object 427F
Index (hex) Name Meaning Flags Default
4280:0 Terminal Table 0 Length of this object RW 64
4280:01 Subindex 001 Register 0 RW 0x0000 (0
dec
)
4280:02 Subindex 002 Register 1 RW 0x0000 (0
dec
)
4280:40 Subindex 064 Register 63 RW 0x0000 (0
dec
)
Index 4281 Terminal Table 0 [HI]: for parameterization of the terminal specified with object 427F
(cont.)
Index (hex) Name Meaning Flags Default
4081:0 Terminal Table 0 Length of this object RW 0
