Parameterization and commissioning
BK11x0, BK1250 69Version: 4.1
Index 4282 Terminal Table 1 [LO]: for parameterization of the terminal specified with object 427F
Index (hex) Name Meaning Flags Default
4282:0 Terminal Table 1 Length of this object RW 64
4282:01 Subindex 001 Register 0 RW 0x0000 (0
dec
)
4282:02 Subindex 002 Register 1 RW 0x0000 (0
dec
)
4282:40 Subindex 064 Register 63 RW 0x0000 (0
dec
)
Index 4283 Terminal Table 1 [HI]: for parameterization of the terminal specified with object 427F
(cont.)
Index (hex) Name Meaning Flags Default
4083:0 Terminal Table 1 Length of this object RW 0
Index 4284 Terminal Table 2 [LO]: for parameterization of the terminal specified with object 427F
Index (hex) Name Meaning Flags Default
4284:0 Terminal Table 2 Length of this object RW 64
4284:01 Subindex 001 Register 0 RW 0x0000 (0
dec
)
4284:02 Subindex 002 Register 1 RW 0x0000 (0
dec
)
4284:40 Subindex 064 Register 63 RW 0x0000 (0
dec
)
Index 4285 Terminal Table 2 [HI]: for parameterization of the terminal specified with object 427F
(cont.)
Index (hex) Name Meaning Flags Default
4085:0 Terminal Table 2 Length of this object RW 0
Index 4286 Terminal Table 3 [LO]: for parameterization of the terminal specified with object 427F
Index (hex) Name Meaning Flags Default
4286:0 Terminal Table 3 Length of this object RW 64
4286:01 Subindex 001 Register 0 RW 0x0000 (0
dec
)
4286:02 Subindex 002 Register 1 RW 0x0000 (0
dec
)
4286:40 Subindex 064 Register 63 RW 0x0000 (0
dec
)
Index 4287 Terminal Table 3 [HI]: for parameterization of the terminal specified with object 427F
(cont.)
Index (hex) Name Meaning Flags Default
4087:0 Terminal Table 3 Length of this object RW 0
Index 6kk0 Terminal Input Data
Note
Mapping
The value ranges of the "kk", "hh", and "ddd" variables of the input and output indices are
shown below [}71]. The dynamic generation of the input and output objects depends on
the order of the terminals in the Bus Terminal block.
Example configuration of the Bus Terminal block
BK1120 - KL1408 - KL2032 - K3403 - KL4032
