Parameterization and commissioning
BK11x0, BK125070 Version: 4.1
Mapping of the assigned PDOs (from index 0x6000)
Index (hex) Name Meaning
6000:0 KL1408 KL1408, max. Subindex (8) Position 1 after the cou-
pler: KL1408
Input data
6000:01 Channel 1 Channel 1, KL1408
6000:02 Channel 2 Channel 2, KL1408
6000:03 Channel 3 Channel 3, KL1408
6000:04 Channel 4 Channel 4, KL1408
6000:05 Channel 5 Channel 5, KL1408
6000:06 Channel 6 Channel 6, KL1408
6000:07 Channel 7 Channel 7, KL1408
6000:08 Channel 8 Channel 8, KL1408
6010:0 not mapped, since no inputs available Position 2 after the cou-
pler: KL2032
6020:0 KL3403 KL3403, max. Subindex (9) Position 3 after the cou-
pler: KL3403
6020:01 Channel 1 Status Channel 1, status, KL3403
6020:02 Channel 1 Word Alig-
ment
Channel 1, word alignment KL3403
6020:03 Channel 1 Data Channel 1, data KL3403
6020:04 Channel 2 Status Channel 2, status, KL3403
6020:05 Channel 2 Word Alig-
ment
Channel 2, word alignment, KL3403
6020:06 Channel 2 Data Channel 2, data, KL3403
6020:07 Channel 3 Status Channel 3, status, KL3403
6020:08 Channel 3 Word Alig-
ment
Channel 3, word alignment, KL3403
6020:09 Channel 3 Data Channel 3, data, KL3403
6030:0 KL4032 KL4032, max. Subindex (6) Position 4 after the cou-
pler: KL4032
6030:01 Channel 1 Status Channel 1, status, KL4032
6030:02 Channel 1 Word Alig-
ment
Channel 1, word alignment KL4032
6030:03 Channel 1 Data Channel 1, data KL4032
6030:04 Channel 2 Status Channel 2, status, KL4032
6030:05 Channel 2 Word Alig-
ment
Channel 2, word alignment KL4032
6030:06 Channel 2 Data Channel 2, data, KL4032
