Beckhoff BK1120 User Manual

Parameterization and commissioning
BK11x0, BK1250 71Version: 4.1
Index (hex) Name Meaning
7000:0 not mapped, since no outputs available Position 1 after the cou-
pler: KL1408
Output data
7010:0 KL2032 KL2032, max. Subindex (2) Position 2 after the cou-
pler: KL2032
7010:01 Channel 1 Channel 1, KL2032
7010:02 Channel 2 Channel 2, KL2032
7020:0 KL3403 KL3403, max. Subindex (9) Position 3 after the cou-
pler: KL3403
7020:01 Channel 1 Status Channel 1, status, KL3403
7020:02 Channel 1 Word Alig-
ment
Channel 1, word alignment KL3403
7020:03 Channel 1 Data Channel 1, data KL3403
7020:04 Channel 2 Status Channel 2, status, KL3403
7020:05 Channel 2 Word Alig-
ment
Channel 2, word alignment, KL3403
7020:06 Channel 2 Data Channel 2, data, KL3403
7020:07 Channel 3 Status Channel 3, status, KL3403
7020:08 Channel 3 Word Alig-
ment
Channel 3, word alignment, KL3403
7020:09 Channel 3 Data Channel 3, data, KL3403
7030:0 KL4032 KL4032, max. Subindex (6) Position 4 after the cou-
pler: KL4032
7030:01 Channel 1 Status Channel 1, status, KL4032
7030:02 Channel 1 Word Alig-
ment
Channel 1, word alignment KL4032
7030:03 Channel 1 Data Channel 1, data KL4032
7030:04 Channel 2 Status Channel 2, status, KL4032
7030:05 Channel 2 Word Alig-
ment
Channel 2, word alignment KL4032
7030:06 Channel 2 Data Channel 2, data, KL4032
Value ranges:
(kk = 00..FF)
hex
, [(hh = 01..FF)
hex
, (ddd = 001..255)
dec
]
Index (hex) Name Meaning Flags Default
6kk0:0 Terminal Input Data [Terminal designation] ROP -
6kk0:01 Channel 001 Channel 001 RO P -
6kk0:hh Channel ddd Channel ddd ROP -
Non-digital terminals (for hh ≥ 03; ddd ≥ 003):
Value ranges:
(kk = 00..FF)
hex
, dec. increment (
hex
)
[(hh = 03..FF)
hex
, (ddd = 003..255)
dec
] for integer values that are divisible by 3 hh or ddd
Index (hex) Name Meaning Flags Default
6kk0:0 Terminal Input Data [Terminal designation] ROP -
6kk0:01 Channel 001 Status Channel 001: Status ROP -
6kk0:02 Channel 001 Word-
Alignment
Channel 001: Word Alignment ROP -
6kk0:03 Channel 001 Data Channel 001: Data ROP -
6kk0:hh-2 Channel ddd/3 Channel ddd/3: Status ROP -
6kk0:hh-1 Channel ddd/3 Channel ddd/3: Word Alignment ROP -
6kk0:hh Channel ddd/3 Channel ddd/3: Data ROP -
Index 7kk0 Terminal Output Data
Digital terminals:
Value ranges:
(kk = 00..FF)
hex
, [(hh = 01..FF)
hex
, (ddd = 001..255)
dec
]
