Beckhoff CU1521 Series - Technical Data

Product overview
CU1521-xxxx, CU156118 Version: 2.5
2.2 Technical data
Technical data CU1521 CU1521-0010 CU1561
Function Ethernet "IP" Media converter Fast Ethernet/100Mbaud (all IEEE 802.3-based
protocols)
IEEE 802.3u auto negotiation, half or full duplex, automatic settings
Link Loss-Forwarding (notification direction configurable)
Store and Forward Mode (FIFO)
unmanaged
Function EtherCAT "EC" Media converter Fast Ethernet/100Mbaud
Cut-through mode
Port handling/link control
Number of Ethernet ports 2
Ethernet interface X1 100BASE-FX
multimode glass fiber
50/125µm (MM)
typically 1300nm
1 x SC Duplex
100BASE-FX single
mode glass fiber
9/125µm (SM)
typically 1300nm
1 x SC Duplex
100BASE-FX-POF
glass fiber 980/1000
µm (POF);
typically 650nm
1 x versatile link for
POF duplex connector
(connector set
ZS1090-0008)
Laser class 1, see note
[}47]
Ethernet interface X2 10BASE-T/100BASE-TX Ethernet/EtherCAT cable (min. CAT 5),
screened
RJ45
Cable length X1 max. max. 2km (100BASE-
FX)
max. 20km (100BASE-
FX)
max. 50m (100BASE-
FX-POF)
Cable length X2 max. up to 100m twisted pair CAT5 (e)
Diagnostics LED: Supply voltage, link/activity X1/X2
EtherCAT: CRC
Power supply via three-pole spring loaded terminal (+, -, PE)
Supply voltage 24V
DC
(18V
DC
to 30V
DC
), protected against polarity reversal.
Current consumption typ. 95mA typ. 80mA typ. 60mA
Weight approx. 105g
Dimensions without plugs (W x H
x D)
approx. 34mm x 98mm x 77mm
Mounting [}23]
on 35 mm mounting rail (mounting rail according to EN 60715)
Permissible ambient temperature
range during operation
-25°C ... +60°C
(extended temperature
range)
0°C …+55°C
Permissible ambient temperature
range during storage
-40°C ... +85°C -25°C ... +85°C
Permissible relative humidity 95%, no condensation
Vibration/shock resistance conforms to EN60068-2-6/ EN60068-2-27, EN60068-2-29
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Marking / Approval
*)
CE, UKCA
cULus [}25]
*) Real applicable approvals/markings see type plate on the side (product marking).
