Mounting and wiring
CU1521-xxxx, CU156122 Version: 2.5
4 Mounting and wiring
4.1 Dimensions
Space requirement in the control cabinet
• The RJ45 connector increase the depth depending on their design and the Ethernet cable used.
• Above the mounting rail an additional height of approx. 10 mm is required to enable latching
[}23] of the switch onto the rail.
CU1521-00x0
Fig.8: CU1521-00x0
CU1561
Fig.9: CU1561
