Commissioning/application notes

CU1521-xxxx, CU156130 Version: 2.5

5.2 Notes on converters with RJ45 fiber-optic connection

Fig.21: CU1521

Mounting rail installation

Mounting

Please ensure that the CU15x1 engages properly on the mounting rail.

See chapter Mounting rail installation [}23].
