Commissioning/Configuration
5.1.2.12 Intel(R) I210 Gigabit Network Connection
Aptio Setup Utility - Copyright (C) American Megatrends, Inc.
► NIC Configuration Identify the physical network port
by blinking the associated LED.
Flashing LEDs 0
UEFI Driver Intel(R) PRO/1000 6.4.13
Adapter PBA Intel i210
Device Name Intel(R) I210 Gigabit
Chip Type Intel i210
PCI Devive ID 1533
PCI Adress 01:00:00
Link Status [Disconnected]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Options
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Quit
MAC address 00:01:05:aa:bb:cc
Version 2.17.1246. Copyright (C) 2014 American Megatrends, Inc.
► NIC Configuration
Setting the physical network parameters (connection speed / Wake on LAN)
Blink LEDs
Options: n = {0 … 15}
Causes the LED at the network port to flash n times.
CX51x0 65Version: 1.6
