Beckhoff CX5130 User Manual

Commissioning/Configuration
5.1.3.1.3 PCI Express Configuration
Aptio Setup Utility - Copyright (C) American Megatrends, Inc.
PCI Express Configuration
PCI Express Port 0 is assigned to LAN 1
PCI Express Port 1 is assigned to LAN 2
PCI Express Port 2 is assigned to CCAT
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Options
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Quit
Version 2.17.1246. Copyright (C) 2014 American Megatrends, Inc.
PCI Express Configuration
Options: none
Shows the mapping of the individual PCI Express ports.
CX51x0 71Version: 1.6
