Appendix
9.2 Image Update
There are two different possibilities to update the image of the CX80xx.
Note
Prerequisites
• Please make sure before the update that your CX80xx supports the image that you
want to load.
• When updating the image, please first update all existing files and only then copy the
new image.
Always copy all files and directories in order to update a CX80xx.
Update via USB
A USB cable is required for this!
• Switch off the CX80xx
• Set red Dip switch (under the flap) DIP 1 to ON
• Switch on the CX
• Connect the PC with USB
• Delete all files (we recommend that you backup all files first), no formatting
• Wait until copying has finished, then remove the USB cable
• Switch DIP switch 1 to OFF
• Switch off the CX80xx
• Switch on the CX80xx; it may take a little longer the first time
CX8080 65Version: 1.0.0
