Beckhoff EL34 Series User Manual

Commissioning
EL34xx 165Version: 1.5
Index F607 PMX Total Reactive
Index (hex) Name Meaning Data type Flags Default
F607:0 PMX Total Reactive Max. subindex UINT8 RO 0x14 (20
dec
)
F607:12 Reactive Energy Recorded reactive energy in mWh INT64 RO
F607:13 Reactive Positive En-
ergy
Received reactive energy in mWh UINT64 RO
F607:14 Reactive Negative
Energy
Supplied reactive energy in mWh UINT64 RO
Index F60B PMX Total Statistic Power
Index (hex) Name Meaning Data type Flags Default
F60B:0 PMX Total Statistic
Power
Max. subindex UINT8 RO 0x19 (25
dec
)
F60B:11 Active Power Avg Average total active power during the last interval in
W
REAL32 RO 0x00000000 (0
dec
)
F60B:12 Active Power Min Minimum total active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
F60B:13 Active Power Max Maximum total active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
F60B:14 Apparent Power Avg Average total apparent power during the last interval
in VA
REAL32 RO 0x00000000 (0
dec
)
F60B:15 Apparent Power Min Minimum total apparent power in the last interval in
VA
REAL32 RO 0x00000000 (0
dec
)
F60B:16 Apparent Power Max Maximum total apparent power in the last interval in
VA
REAL32 RO 0x00000000 (0
dec
)
F60B:17 Reactive Power Avg Average total reactive power average during the last
interval in Var
REAL32 RO 0x00000000 (0
dec
)
F60B:18 Reactive Power Min Minimum total reactive power in the last interval in
Var
REAL32 RO 0x00000000 (0
dec
)
F60B:19 Reactive Power Max Maximum total reactive power in the last interval in
Var
REAL32 RO 0x00000000 (0
dec
)
Index F60C PMX Total Statistic PQF
Index (hex) Name Meaning Data type Flags Default
F60C:0 PMX Total Statistic
PQF
Max. subindex UINT8 RO 0x13 (19
dec
)
F60C:11 PQF Avg Average value of the power quality factor during the
last interval
REAL32 RO 0x00000000 (0
dec
)
F60C:12 PQF Min Minimum power quality factor in the last interval REAL32 RO 0x00000000 (0
dec
)
F60C:13 PQF Max Maximum power quality factor in the last interval REAL32 RO 0x00000000 (0
dec
)
