Beckhoff EL34 Series User Manual

Commissioning
EL34xx166 Version: 1.5
Index F60D PMX Total Interval Energy
Index (hex) Name Meaning Data type Flags Default
F60D:0 PMX Total Interval
Energy
Max. subindex UINT8 RO 0x19 (25
dec
)
F60D:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00 (0
dec
)
F60D:11 Active Energy Recorded total active energy during the last interval
in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:12 Active Energy
Positive
Received total active energy during the last interval in
Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:13 Active Energy Nega-
tive
Supplied total active energy during at last interval in
Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:14 Apparent Energy Recorded total apparent energy during the last inter-
val in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:15 Apparent Energy
Positive
Received total apparent energy during the last inter-
val in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:16 Apparent Energy
Negative
Supplied total apparent energy during the last interval
in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:17 Reactive Energy Recorded total reactive energy during the last interval
in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:18 Reactive Energy Posi-
tive
Received total reactive energy during the last interval
in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:19 Reactive Energy Neg-
ative
Supplied total reactive energy during the last interval
in Wh
REAL32 RO 0x00000000 (0
dec
)
Index F612 PMX Total Active Reduced
Index (hex) Name Meaning Data type Flags Default
F612:0 PMX Total Active Re-
duced
Max. subindex UINT8 RO 0x12 (18
dec
)
F612:11 Active Power Active power in W REAL32 RO 0x00000000 (0
dec
)
F612:12 Active Energy Active energy in mWh INT64 RO 0x00000000 (0
dec
)
Index F613 PMX Total Apparent Reduced
Index (hex) Name Meaning Data type Flags Default
F613:0 PMX Total Apparent
Reduced
Max. subindex UINT8 RO 0x12 (18
dec
)
F613:11 Apparent Power Apparent power in VA REAL32 RO 0x00000000 (0
dec
)
F613:12 Apparent Energy Apparent energy in mVAh INT64 RO 0x00000000 (0
dec
)
Index F614 PMX Total Reactive Reduced
Index (hex) Name Meaning Data type Flags Default
F614:0 PMX Total Reactive
Reduced
Max. subindex UINT8 RO 0x12 (18
dec
)
F614:11 Reactive Power Reactive power in var REAL32 RO 0x00000000 (0
dec
)
F614:12 Reactive Energy Reactive energy in mvarh INT64 RO 0x00000000 (0
dec
)
Index F615 PMX Total Interval Energy Reduced
Index (hex) Name Meaning Data type Flags Default
F615:0 PMX Total Interval
Energy Reduced
Max. subindex UINT8 RO 0x13 (19
dec
)
F615:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00000000 (0
dec
)
F615:11 Active Energy Balanced total effective energy in the last interval in
Wh
REAL32 RO 0x00000000 (0
dec
)
F615:12 Apparent Energy Balanced total apparent energy in the last interval in
VAh
REAL32 RO 0x00000000 (0
dec
)
F615:13 Reactive Energy Balanced total reactive energy in the last interval in
var
REAL32 RO 0x00000000 (0
dec
)
