Index 90n3 PMX info data energy (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
90n3:0 PMX info data energy
ch.1
Max. subindex UINT8 RO 0x19 (25
dec
)
90n3:11 Active Energy Recorded active phase energy in mWh INT64 RO
90n3:12 Positive Active En-
ergy
Received active phase energy in mWh UINT64 RO
90n3:13 Negative Active En-
ergy
Supplied active phase energy in mWh UINT64 RO
90n3:14 Apparent Energy Recorded apparent phase energy in mWh INT64 RO
90n3:15 Positive Apparent En-
ergy
Received apparent phase energy in mWh UINT64 RO
90n3:16 Negative Apparent
Energy
Supplied apparent phase energy in mWh UINT64 RO
90n3:17 Reactive Energy Recorded reactive phase energy in mWh INT64 RO
90n3:18 Positive Reactive En-
ergy
Received reactive phase energy in mWh UINT64 RO
90n3:19 Negative Reactive
Energy
Supplied reactive phase energy in mWh UINT64 RO
Index A0n0 PMX Diag data (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
A0n0:0 PMX diag data ch.1 Max. subindex UINT8 RO 0x12 (18
dec
)
A0n0:11 Saturation Time Volt-
age
Time (in 0.1 ms) in which the terminal has measured
an overvoltage.
UINT32 RO 0x00000000 (0
dec
)
A0n0:12 Saturation Time Cur-
rent
Time (in 0.1 ms) in which the terminal has measured
an overcurrent.
UINT32 RO 0x00000000 (0
dec
)
Index F081 Download revision
Index (hex) Name Meaning Data type Flags Default
F081:0 Download revision Max. subindex UINT8 RO 0x01 (1
dec
)
F010:01 Revision number Configured revision of the terminal,
(see note)
UINT32 RW 0x00000000 (0
dec
)
Index F80F PM Vendor data
Index (hex) Name Meaning Data type Flags Default
F80F:0 PMX Vendor data Max. subindex UINT8 RO 0x11 (17
dec
)
F80F:11 Type Vendor-specific data UINT32 RW 0x00000000 (0
dec
)
Index F902 PMX Total Info data Power
Index (hex) Name Meaning Data type Flags Default
F902:0 PMX Total Info data
Power
Max subindex UINT8 RO 0x19 (25
dec
)
F902:11 Active Power Avg Average total active power during the last interval in
W
REAL32 RO 0x00000000 (0
dec
)
F902:12 Active Power Min Minimum total active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
F902:13 Active Power Max Maximum total active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
F902:14 Apparent Power Avg Average total apparent power during the last interval
in VA
REAL32 RO 0x00000000 (0
dec
)
F902:15 Apparent Power Min Minimum total apparent power in the last interval in
VA
REAL32 RO 0x00000000 (0
dec
)
F902:16 Apparent Power Max Maximum total apparent power in the last interval in
VA
REAL32 RO 0x00000000 (0
dec
)
F902:17 Reactive Power Avg Average total reactive power average during the last
interval in var
REAL32 RO 0x00000000 (0
dec
)
F902:18 Reactive Power Min Minimum total reactive power in the last interval in
var
REAL32 RO 0x00000000 (0
dec
)
F902:19 Reactive Power Max Maximum total reactive power in the last interval in
var
REAL32 RO 0x00000000 (0
dec
)
