Beckhoff EL34 Series User Manual

Commissioning
EL34xx186 Version: 1.5
Index 60n1 PMX Basic (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n1:0 PMX Basic Max. Subindex UINT8 RO 0x12 (18
dec
)
60n1:11 Voltage RMS value of the voltage in V REAL32 RO 0x00000000 (0
dec
)
60n1:12 Current RMS value of the current in A REAL32 RO 0x00000000 (0
dec
)
Index 60n2 PMX Power (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n2:0 PMX Power Max Subindex UINT8 RO 0x14 (20
dec
)
60n2:11 Active power Active power in W REAL32 RO 0x00000000 (0
dec
)
60n2:12 Apparent Power Apparent power in VA REAL32 RO 0x00000000 (0
dec
)
60n2:13 Reactive Power Reactive power in var REAL32 RO 0x00000000 (0
dec
)
60n2:14 Power Factor Power factor REAL32 RO 0x00000000 (0
dec
)
Index 60n4 PMX Energy (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n4:0 PMX Energy Max. subindex UINT8 RO 0x13 (19
dec
)
60n4:11 Active Energy Active energy in mWh INT64 RO
60n4:12 Apparent Energy Apparent energy in mVAh INT64 RO
60n4:13 Reactive Energy Reactive energy in mvarh INT64 RO
Index 60n6 PMX Timing (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n6:0 PMX Timing Max Subindex UINT8 RO 0x12 (18
dec
)
60n6:12 Voltage Last Zero
Crossing
Last detected voltage zero crossing as distributed
clock time
UINT64 RO
Index 60n7 PMX Advanced (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n7:0 PMX Advanced Max Subindex UINT8 RO 0x14 (20
dec
)
60n7:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00 (0
dec
)
60n7:11 Voltage Total Har-
monic Distortion
"Total Harmonic Distortion" is the distortion factor of
the voltage. It indicates the ratio of the harmonic
components of an oscillation relative to its fundamen-
tal in %.
REAL32 RO 0x00000000 (0
dec
)
60n7:12 Current Distortion
Factor
The "Current Distortion Factor" is also referred to as
TDD (Total Demand Distortion). It indicates the ratio
between the current harmonics and the maximum
current (EL3443: 1A and EL3443-0010: 5A). Speci-
fied in % of the maximum current.
REAL32 RO 0x00000000 (0
dec
)
60n7:13 Current Total Har-
monic Distortion
"Total Harmonic Distortion" is the distortion factor of
the current. It indicates the ratio of the harmonic com-
ponents of an oscillation relative to its fundamental in
%.
REAL32 RO 0x00000000 (0
dec
)
60n7:14 Cos phi Phase angle of the fundamental wave in degrees REAL32 RO 0x00000000 (0
dec
)
Index 60n8 PMX Statistic Voltage (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n8:0 PMX Statistic Voltage Max Subindex UINT8 RO 0x13 (19
dec
)
60n8:11 Voltage Peak Peak value of the instantaneous voltage in the last in-
terval in V
REAL32 RO 0x00000000 (0
dec
)
60n8:12 Voltage RMS Mini-
mum
Minimum RMS value of the voltage in the last interval
in V
REAL32 RO 0x00000000 (0
dec
)
60n8:13 Voltage RMS Maxi-
mum
Maximum RMS value of the voltage in the last inter-
val in V
REAL32 RO 0x00000000 (0
dec
)
