Commissioning
EL34xx 189Version: 1.5
Index F603 PMX Total Active
Index (hex) Name Meaning Data type Flags Default
F603:0 PMX Total Active Max. subindex UINT8 RO 0x14 (20
dec
)
F603:11 Active Power Active power in W INT64 RO
F603:12 Active Energy Recorded active energy in mWh INT64 RO
F603:13 Active Positive Energy Received active energy in mWh INT64 RO
F603:14 Active Negative En-
ergy
Supplied active energy in mWh INT64 RO
Index F605 PMX Total Apparent
Index (hex) Name Meaning Data type Flags Default
F605:0 PMX Total Apparent Max. subindex UINT8 RO 0x14 (20
dec
)
F605:11 Apparent Power Balanced apparent power in VA INT64 RO
F605:12 Apparent Energy Recorded apparent energy in mWh INT64 RO
F605:13 Apparent Positive En-
ergy
Received apparent energy in mWh UINT64 RO
F605:14 Apparent Negative
Energy
Supplied apparent energy in mWh UINT64 RO
Index F607 PMX Total Reactive
Index (hex) Name Meaning Data type Flags Default
F607:0 PMX Total Reactive Max. subindex UINT8 RO 0x14 (20
dec
)
F607:11 Reactive Power Balanced reactive power in Var INT64 RO
F607:12 Reactive Energy Recorded reactive energy in mWh INT64 RO
F607:13 Reactive Positive En-
ergy
Received reactive energy in mWh UINT64 RO
F607:14 Reactive Negative
Energy
Supplied reactive energy in mWh UINT64 RO
Index F609 PMX Total L-L Voltages
Index (hex) Name Meaning Data type Flags Default
F609:0 PMX Total L-L Volt-
ages
Max. subindex UINT8 RO 0x13 (19
dec
)
F609:11 L1-L2 Voltage RMS value of the phase-to-phase voltage between
L1 and L2 in V
REAL32 RO 0x00000000 (0
dec
)
F609:12 L2-L3 Voltage RMS value of the phase-to-phase voltage between
L2 and L3 in V
REAL32 RO 0x00000000 (0
dec
)
F609:13 L3-L1 Voltage RMS value of the phase-to-phase voltage between
L3 and L1 in V
REAL32 RO 0x00000000 (0
dec
)
Index F60A PMX Variant Value In
Index (hex) Name Meaning Data type Flags Default
F60A:0 PMX Variant Value In Max. subindex UINT8 RO 0x18 (24
dec
)
F60A:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00 (0
dec
)
F60A:11 Index 1 REAL Acknowledge for variable output value 1 UINT16 RO 0x0000 (0
dec
)
F60A:12 Value 1 REAL variable output value channel 1 REAL32 RO 0x00000000 (0
dec
)
F60A:13 Index 2 REAL Acknowledge for variable output value 2 UINT16 RO 0x0000 (0
dec
)
F60A:14 Value 2 REAL variable output value channel 2 REAL32 RO 0x00000000 (0
dec
)
F60A:15 Index 3 REAL Acknowledge for variable output value 3 UINT16 RO 0x0000 (0
dec
)
F60A:16 Value 3 REAL variable output value channel 3 REAL32 RO 0x00000000 (0
dec
)
F60A:17 Index 4 ULINT Acknowledge for variable output value 4 UINT16 RO 0x0000 (0
dec
)
F60A:18 Value 4 ULINT variable output value channel 4 UINT64 RO
