Beckhoff EL34 Series User Manual

Commissioning
EL34xx190 Version: 1.5
Index F60B PMX Total Statistic Power
Index (hex) Name Meaning Data type Flags Default
F60B:0 PMX Total Statistic
Power
Max. subindex UINT8 RO 0x19 (25
dec
)
F60B:11 Active Power Avg Average total active power during the last interval in
W
REAL32 RO 0x00000000 (0
dec
)
F60B:12 Active Power Min Minimum total active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
F60B:13 Active Power Max Maximum total active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
F60B:14 Apparent Power Avg Average total apparent power during the last interval
in VA
REAL32 RO 0x00000000 (0
dec
)
F60B:15 Apparent Power Min Minimum total apparent power in the last interval in
VA
REAL32 RO 0x00000000 (0
dec
)
F60B:16 Apparent Power Max Maximum total apparent power in the last interval in
VA
REAL32 RO 0x00000000 (0
dec
)
F60B:17 Reactive Power Avg Average total reactive power average during the last
interval in Var
REAL32 RO 0x00000000 (0
dec
)
F60B:18 Reactive Power Min Minimum total reactive power in the last interval in
Var
REAL32 RO 0x00000000 (0
dec
)
F60B:19 Reactive Power Max Maximum total reactive power in the last interval in
Var
REAL32 RO 0x00000000 (0
dec
)
Index F60C PMX Total Statistic PQF
Index (hex) Name Meaning Data type Flags Default
F60C:0 PMX Total Statistic
PQF
Max. subindex UINT8 RO 0x13 (19
dec
)
F60C:11 PQF Avg Average value of the power quality factor during the
last interval
REAL32 RO 0x00000000 (0
dec
)
F60C:12 PQF Min Minimum power quality factor in the last interval REAL32 RO 0x00000000 (0
dec
)
F60C:13 PQF Max Maximum power quality factor in the last interval REAL32 RO 0x00000000 (0
dec
)
Index F60D PMX Total Interval Energy
Index (hex) Name Meaning Data type Flags Default
F60D:0 PMX Total Interval
Energy
Max. subindex UINT8 RO 0x19 (25
dec
)
F60D:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00 (0
dec
)
F60D:11 Active Energy Recorded total active energy during the last interval
in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:12 Active Energy
Positive
Received total active energy during the last interval in
Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:13 Active Energy Nega-
tive
Supplied total active energy during at last interval in
Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:14 Apparent Energy Recorded total apparent energy during the last inter-
val in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:15 Apparent Energy
Positive
Received total apparent energy during the last inter-
val in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:16 Apparent Energy
Negative
Supplied total apparent energy during the last interval
in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:17 Reactive Energy Recorded total reactive energy during the last interval
in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:18 Reactive Energy Posi-
tive
Received total reactive energy during the last interval
in Wh
REAL32 RO 0x00000000 (0
dec
)
F60D:19 Reactive Energy Neg-
ative
Supplied total reactive energy during the last interval
in Wh
REAL32 RO 0x00000000 (0
dec
)
Index F612 PMX Total Active Reduced
Index (hex) Name Meaning Data type Flags Default
F612:0 PMX Total Active Re-
duced
Max. subindex UINT8 RO 0x12 (18
dec
)
F612:11 Active Power Active power in W REAL32 RO 0x00000000 (0
dec
)
F612:12 Active Energy Active energy in mWh INT64 RO 0x00000000 (0
dec
)
