Beckhoff EL34 Series User Manual

Commissioning
EL34xx 191Version: 1.5
Index F613 PMX Total Apparent Reduced
Index (hex) Name Meaning Data type Flags Default
F613:0 PMX Total Apparent
Reduced
Max. subindex UINT8 RO 0x12 (18
dec
)
F613:11 Apparent Power Apparent power in VA REAL32 RO 0x00000000 (0
dec
)
F613:12 Apparent Energy Apparent energy in mVAh INT64 RO 0x00000000 (0
dec
)
Index F614 PMX Total Reactive Reduced
Index (hex) Name Meaning Data type Flags Default
F614:0 PMX Total Reactive
Reduced
Max. subindex UINT8 RO 0x12 (18
dec
)
F614:11 Reactive Power Reactive power in var REAL32 RO 0x00000000 (0
dec
)
F614:12 Reactive Energy Reactive energy in mvarh INT64 RO 0x00000000 (0
dec
)
Index F615 PMX Total Interval Energy Reduced
Index (hex) Name Meaning Data type Flags Default
F615:0 PMX Total Interval
Energy Reduced
Max. subindex UINT8 RO 0x13 (19
dec
)
F615:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00000000 (0
dec
)
F615:11 Active Energy Balanced total effective energy in the last interval in
Wh
REAL32 RO 0x00000000 (0
dec
)
F615:12 Apparent Energy Balanced total apparent energy in the last interval in
VAh
REAL32 RO 0x00000000 (0
dec
)
F615:13 Reactive Energy Balanced total reactive energy in the last interval in
var
REAL32 RO 0x00000000 (0
dec
)
6.7.3.5 Output data
Index F700 PMX Variant Value Out
Index (hex) Name Meaning Data type Flags Default
F700:0 PMX Variant Value
Out
Max. subindex UINT8 RO 0x14 (20
dec
)
F700:11 Index 1 REAL Request for variable output value 1 (REAL)
Can be used for all non-energy values (details see
settings)
UINT16 RO 0x0000 (0
dec
)
F700:12 Index 2 REAL Request for variable output value 2 (REAL)
Can be used for all non-energy values (details see
settings)
UINT16 RO 0x0000 (0
dec
)
F700:13 Index 3 REAL Request for variable output value 3 (REAL)
Can be used for all non-energy values (details see
settings)
UINT16 RO 0x0000 (0
dec
)
F700:14 Index 4 ULINT Request for variable output value 4 (ULINT)
Can be used for all energy values (which are output
as ULINT): 45-59 and 1069-1083
UINT16 RO 0x0000 (0
dec
)
Index F701 PMX Interval
Index (hex) Name Meaning Data type Flags Default
F701:0 PMX Interval Max. subindex UINT8 RO 0x01 (1
dec
)
F701:01 Reset Interval Manual option for resetting the interval (see basic
function principles – Statistical evaluation)
BOOLEAN RO 0x00 (0
dec
)
