Beckhoff EL34 Series User Manual

Commissioning
EL34xx192 Version: 1.5
6.7.3.6 Information and diagnostic data
Index 90n0 PMX info data voltage (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
90n0:0 PMX Info data Volt-
age
Max. subindex UINT8 RO 0x13 (19
dec
)
90n0:11 Voltage Peak Peak value of the instantaneous voltage in the last in-
terval in V
REAL32 RO 0x00000000 (0
dec
)
90n0:12 Voltage RMS Mini-
mum
Minimum RMS value of the voltage in the last interval
in V
REAL32 RO 0x00000000 (0
dec
)
90n0:13 Voltage RMS Maxi-
mum
Maximum RMS value of the voltage in the last inter-
val in V
REAL32 RO 0x00000000 (0
dec
)
Index 90n1 PMX info data current (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
90n1:0 PMX Info data Cur-
rent
Max. subindex UINT8 RO 0x13 (19
dec
)
90n1:11 Current Peak Peak value of the instantaneous current in the last in-
terval in A
REAL32 RO 0x00000000 (0
dec
)
90n1:12 Current RMS Mini-
mum
Minimum RMS value of the current in the last interval
in A
REAL32 RO 0x00000000 (0
dec
)
90n1:13 Current RMS Maxi-
mum
Maximum RMS value of the current in the last inter-
val in A
REAL32 RO 0x00000000 (0
dec
)
Index 90n2 PMX info data power (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
90n2:0 PMX Info data Power Max. subindex UINT8 RO 0x1B (27
dec
)
90n2:11 Active Power Avg Average active phase power during the last interval
in W
REAL32 RO 0x00000000 (0
dec
)
90n2:12 Active Power Min Minimum active phase power during the last interval
in W
REAL32 RO 0x00000000 (0
dec
)
90n2:13 Active Power Max Maximum active phase power during the last interval
in W
REAL32 RO 0x00000000 (0
dec
)
90n2:14 Apparent Power Avg Average apparent phase power during the last inter-
val in VA
REAL32 RO 0x00000000 (0
dec
)
90n2:15 Apparent Power Min Minimum apparent phase power during the last inter-
val in VA
REAL32 RO 0x00000000 (0
dec
)
90n2:16 Apparent Power Max Maximum apparent phase power during the last inter-
val in VA
REAL32 RO 0x00000000 (0
dec
)
90n2:17 Reactive Power Avg Average reactive phase power during the last interval
in var
REAL32 RO 0x00000000 (0
dec
)
90n2:18 Reactive Power Min Minimum reactive phase power during the last inter-
val in var
REAL32 RO 0x00000000 (0
dec
)
90n2:19 Reactive Power Max Maximum reactive phase power during the last inter-
val in var
REAL32 RO 0x00000000 (0
dec
)
90n2:1A Phi Phase angle in degrees (between voltage U_Lx and
the corresponding current I_Lx)
REAL32 RO 0x00000000 (0
dec
)
90n2:1B Phase angle Phase difference in degrees (between different volt-
ages U_Lx and U_Ly)
REAL32 RO 0x00000000 (0
dec
)
