Beckhoff EL34 Series User Manual

Commissioning
EL34xx 193Version: 1.5
Index 90n3 PMX info data energy (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
90n3:0 PMX info data energy
ch.1
Max. subindex UINT8 RO 0x19 (25
dec
)
90n3:11 Active Energy Recorded active phase energy in mWh INT64 RO
90n3:12 Positive Active En-
ergy
Received active phase energy in mWh UINT64 RO
90n3:13 Negative Active En-
ergy
Supplied active phase energy in mWh UINT64 RO
90n3:14 Apparent Energy Recorded apparent phase energy in mWh INT64 RO
90n3:15 Positive Apparent En-
ergy
Received apparent phase energy in mWh UINT64 RO
90n3:16 Negative Apparent
Energy
Supplied apparent phase energy in mWh UINT64 RO
90n3:17 Reactive Energy Recorded reactive phase energy in mWh INT64 RO
90n3:18 Positive Reactive En-
ergy
Received reactive phase energy in mWh UINT64 RO
90n3:19 Negative Reactive
Energy
Supplied reactive phase energy in mWh UINT64 RO
Index 90n4 PMX Harmonic Voltage (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
90n4:0 PMX Harmonic Volt-
age Ch.1
Max. subindex UINT8 RO 0x2A (42
dec
)
90n4:01 Harmonic 0 DC component of the oscillation in % of the funda-
mental wave
REAL32 RO 0x00000000 (0
dec
)
90n4:02 Harmonic 1 Fundamental wave REAL32 RO 0x00000000 (0
dec
)
90n4:03 Harmonic 2 Second harmonic in % of the fundamental wave REAL32 RO 0x00000000 (0
dec
)
90n4:04 Harmonic 3 Third harmonic in % of the fundamental wave REAL32 RO 0x00000000 (0
dec
)
… … … … … …
90n4:2A Harmonic 41 41st harmonic in % of the fundamental wave REAL32 RO 0x00000000 (0
dec
)
Index 90n5 PMX Harmonic Current (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
90n5:0 PMX Harmonic Volt-
age Ch.1
Max. subindex UINT8 RO 0x2A (42
dec
)
90n5:01 Harmonic 0 DC component of the oscillation in % of the funda-
mental wave
REAL32 RO 0x00000000 (0
dec
)
90n5:02 Harmonic 1 Fundamental wave REAL32 RO 0x00000000 (0
dec
)
90n5:03 Harmonic 2 2nd harmonic in % of the fundamental wave REAL32 RO 0x00000000 (0
dec
)
90n5:04 Harmonic 3 3rd harmonic in % of the fundamental wave REAL32 RO 0x00000000 (0
dec
)
… … … … … …
90n5:2A Harmonic 41 41st harmonic in % of the fundamental wave REAL32 RO 0x00000000 (0
dec
)
Index A0n0 PMX Diag data (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
A0n0:0 PMX diag data ch.1 Max. subindex UINT8 RO 0x12 (18
dec
)
A0n0:11 Saturation Time Volt-
age
Time (in 0.1 ms) in which the terminal has measured
an overvoltage.
UINT32 RO 0x00000000 (0
dec
)
A0n0:12 Saturation Time Cur-
rent
Time (in 0.1 ms) in which the terminal has measured
an overcurrent.
UINT32 RO 0x00000000 (0
dec
)
Index F081 Download revision
Index (hex) Name Meaning Data type Flags Default
F081:0 Download revision Max. subindex UINT8 RO 0x01 (1
dec
)
F010:01 Revision number Configured revision of the terminal,
(see note)
UINT32 RW 0x00000000 (0
dec
)
