Beckhoff EL34 Series User Manual

Commissioning
EL34xx194 Version: 1.5
Index F80F PM Vendor data
Index (hex) Name Meaning Data type Flags Default
F80F:0 PMX Vendor data Max. subindex UINT8 RO 0x11 (17
dec
)
F80F:11 Type Vendor-specific data UINT32 RW 0x00000000 (0
dec
)
Index F902 PMX Total Info data Power
Index (hex) Name Meaning Data type Flags Default
F902:0 PMX Total Info data
Power
Max subindex UINT8 RO 0x19 (25
dec
)
F902:11 Active Power Avg Average total active power during the last interval in
W
REAL32 RO 0x00000000 (0
dec
)
F902:12 Active Power Min Minimum total active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
F902:13 Active Power Max Maximum total active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
F902:14 Apparent Power Avg Average total apparent power during the last interval
in VA
REAL32 RO 0x00000000 (0
dec
)
F902:15 Apparent Power Min Minimum total apparent power in the last interval in
VA
REAL32 RO 0x00000000 (0
dec
)
F902:16 Apparent Power Max Maximum total apparent power in the last interval in
VA
REAL32 RO 0x00000000 (0
dec
)
F902:17 Reactive Power Avg Average total reactive power average during the last
interval in var
REAL32 RO 0x00000000 (0
dec
)
F902:18 Reactive Power Min Minimum total reactive power in the last interval in
var
REAL32 RO 0x00000000 (0
dec
)
F902:19 Reactive Power Max Maximum total reactive power in the last interval in
var
REAL32 RO 0x00000000 (0
dec
)
Index F903 PMX Total Info data Energy
Index (hex) Name Meaning Data type Flags Default
F903:0 PMX Total Info data
Energy
Max. subindex UINT8 RO 0x19 (25
dec
)
F903:11 Active Energy Recorded total active energy in mWh INT64 RO
F903:12 Positive Active En-
ergy
Received total active energy in mWh UINT64 RO
F903:13 Negative Active En-
ergy
Supplied total active energy in mWh UINT64 RO
F903:14 Apparent Energy Recorded total apparent energy in mWh INT64 RO
F903:15 Positive Apparent En-
ergy
Received total apparent energy in mWh UINT64 RO
F903:16 Negative Apparent
Energy
Supplied total apparent energy in mWh UINT64 RO
F903:17 Reactive Energy Recorded total reactive energy in mWh INT64 RO
F903:18 Positive Reactive En-
ergy
Received total reactive energy in mWh UINT64 RO
F903:19 Negative Reactive
Energy
Supplied total reactive energy in mWh UINT64 RO
Index F904 PMX Total Info data PQF
Index (hex) Name Meaning Data type Flags Default
F904:0 PMX Total Info data
PQF
Max. subindex UINT8 RO 0x13 (19
dec
)
F904:11 PQF Avg Average value of the power quality factor during the
last interval
REAL32 RO 0x00000000 (0
dec
)
F904:12 PQF Min Minimum power quality factor in the last interval REAL32 RO 0x00000000 (0
dec
)
F904:13 PQF Max Maximum power quality factor in the last interval REAL32 RO 0x00000000 (0
dec
)
