Beckhoff EL34 Series User Manual

Commissioning
EL34xx 195Version: 1.5
Index FA00 PMX Diag data
Index (hex) Name Meaning Data type Flags Default
FA00:0 PMX Diag data Max. subindex UINT8 RO 0x13 (19
dec
)
FA00:11 Min CPU Die Temper-
ature
Minimum CPU temperature measured so far REAL32 RO 0x00000000 (0
dec
)
FA00:12 Max CPU Die Tem-
perature
Maximum CPU temperature measured so far REAL32 RO 0x00000000 (0
dec
)
FA00:13 EBUS Voltage Current E-bus voltage REAL32 RO 0x00000000 (0
dec
)
6.7.3.7 Standard objects
Standard objects (0x1000-0x1FFF)
The standard objects have the same meaning for all EtherCAT slaves.
Index 1000 Device type
Index (hex) Name Meaning Data type Flags Default
1000:0 Device type Device type of the EtherCAT slave: The Lo-Word
contains the CoE profile used (5001). The Hi-Word
contains the module profile according to the modular
device profile.
UINT32 RO 0x01551389
(22352777
dec
)
Index 1008 Device name
Index (hex) Name Meaning Data type Flags Default
1008:0 Device name Device name of the EtherCAT slave STRING RO EL34xx
Index 1009 Hardware version
Index (hex) Name Meaning Data type Flags Default
1009:0 Hardware version Hardware version of the EtherCAT slave STRING RO
Index 100A Software Version
Index (hex) Name Meaning Data type Flags Default
100A:0 Software version Firmware version of the EtherCAT slave STRING RO
Index 100B Bootloader version
Index (hex) Name Meaning Data type Flags Default
100B:0 Bootloader version Bootloader version STRING RO
Index 1018 Identity
Index (hex) Name Meaning Data type Flags Default
1018:0 Identity Information for identifying the slave UINT8 RO 0x04 (4
dec
)
1018:01 Vendor ID Vendor ID of the EtherCAT slave UINT32 RO 0x00000002 (2
dec
)
1018:02 Product code Product code of the EtherCAT slave UINT32 RO 0x0D733052
(225652818
dez
)
1018:03 Revision Revision numberof the EtherCAT slave; the low
word (bit 0-15) indicates the special terminal number,
the high word (bit 16-31) refers to the device descrip-
tion
UINT32 RO 0x00000000 (0
dec
)
1018:04 Serial number Serial number of the EtherCAT slave; the low byte
(bit 0-7) of the low word contains the year of produc-
tion, the high byte (bit 8-15) of the low word contains
the week of production, the high word (bit 16-31) is 0
UINT32 RO e.g. 0x00001E06
(KW 30/2006)
