Index 1A27 Total TxPDO-Map Statistic PQF
Index (hex) Name Meaning Data type Flags Default
1A27:0 Total TxPDO-Map
Statistic PQF
PDO Mapping TxPDO 40 UINT8 RO 0x03 (3
dec
)
1A27:01 SubIndex 001 1. PDO Mapping entry (object 0xF60C (PMX Total
Statistic PQF), entry 0x11 (PQF Avg))
UINT32 RO 0xF60C:11, 32
1A27:02 SubIndex 002 2. PDO Mapping entry (object 0xF60C (PMX Total
Statistic PQF), entry 0x12 (PQF Min))
UINT32 RO 0xF60C:12, 32
1A27:03 SubIndex 003 3. PDO Mapping entry (object 0xF60C (PMX Total
Statistic PQF), entry 0x13 (PQF Max))
UINT32 RO 0xF60C:13, 32
Index 1A28 Total TxPDO-Map Interval Energy
Index (hex) Name Meaning Data type Flags Default
1A28:0 Total TxPDO-Map In-
terval Energy
PDO Mapping TxPDO 41 UINT8 RO 0x0B (11
dec
)
1A28:01 SubIndex 001 1. PDO Mapping entry (15 bits align) UINT32 RO 0x0000:00, 15
1A28:02 SubIndex 002 2. PDO Mapping entry (object 0xF60D (PMX Total In-
terval Energy), entry 0x10 (TxPDO Toggle))
UINT32 RO 0xF60D:10, 1
1A28:03 SubIndex 003 3. PDO Mapping entry (object 0xF60D (PMX Total In-
terval Energy), entry 0x11 (Active Energy))
UINT32 RO 0xF60D:11, 32
1A28:04 SubIndex 004 4. PDO Mapping entry (object 0xF60D (PMX Total In-
terval Energy), entry 0x12 (Active Energy Positive))
UINT32 RO 0xF60D:12, 32
1A28:05 SubIndex 005 5. PDO Mapping entry (object 0xF60D (PMX Total In-
terval Energy), entry 0x13 (Active Energy Negative))
UINT32 RO 0xF60D:13, 32
1A28:06 SubIndex 006 6. PDO Mapping entry (object 0xF60D (PMX Total In-
terval Energy), entry 0x14 (Apparent Energy))
UINT32 RO 0xF60D:14, 32
1A28:07 SubIndex 007 7. PDO Mapping entry (object 0xF60D (PMX Total In-
terval Energy), entry 0x15 (Apparent Energy Posi-
tive))
UINT32 RO 0xF60D:15, 32
1A28:08 SubIndex 008 8. PDO Mapping entry (object 0xF60D (PMX Total In-
terval Energy), entry 0x16 (Apparent Energy Nega-
tive))
UINT32 RO 0xF60D:16, 32
1A28:09 SubIndex 009 9. PDO Mapping entry (object 0xF60D (PMX Total In-
terval Energy), entry 0x17 (Reactive Energy))
UINT32 RO 0xF60D:17, 32
1A28:0A SubIndex 010 10. PDO Mapping entry (object 0xF60D (PMX Total
Interval Energy), entry 0x18 (Reactive Energy Posi-
tive))
UINT32 RO 0xF60D:18, 32
1A28:0B SubIndex 011 11. PDO Mapping entry (object 0xF60D (PMX Total
Interval Energy), entry 0x19 (Reactive Energy Nega-
tive))
UINT32 RO 0xF60D:19, 32
Index 1A29 Total TxPDO-Map Active Reduced
Index (hex) Name Meaning Data type Flags Default
1A29:0 Total TxPDO-Map Ac-
tive Reduced
PDO Mapping TxPDO 35 UINT8 RO 0x02 (2
dec
)
1A29:01 SubIndex 001 1. PDO Mapping entry (Alignet)) UINT32 RO 0x0000:00, 32
1A29:02 SubIndex 002 2. PDO Mapping entry (object 0xF612 (PMX Total
Apparent), entry 0x12 (Active Reduced))
UINT32 RO 0xF612:12, 64
Index 1A2A Total TxPDO-Map Apparent Reduced
Index (hex) Name Meaning Data type Flags Default
1A2A:0 Total TxPDO-Map Ap-
parent Reduced
PDO Mapping TxPDO 35 UINT8 RO 0x02 (2
dec
)
1A2A:01 SubIndex 001 1. PDO Mapping entry (object 0xF613 (PMX Total
Apparent Reduced), entry 0x11 (Apparent Power))
UINT32 RO 0xF613:11, 32
1A2A:02 SubIndex 002 2. . PDO Mapping entry (object 0xF613 (PMX Total
Apparent Reduced), entry 0x12 (Apparent Energy))
UINT32 RO 0xF613:12, 64
