Commissioning
EL34xx212 Version: 1.5
Index 80n2 PMX User Scale (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
80n2:0 PMX User Scale Ch.1 Max. subindex UINT8 RO 0x15 (21
dec
)
80n2:01 User Calibration En-
able
Set to true to enable user calibration data. BOOLEAN RW 0x00 (0
dec
)
80n2:11 User Calibration Volt-
age Offset
Value in V REAL32 RW 0x00000000 (0
dec
)
80n2:12 User Calibration Volt-
age Gain
Factor (without unit) REAL32 RW 0x3F800000
(1065353216
dec
)
80n2:13 User Calibration Cur-
rent Offset
Value in A REAL32 RW 0x00000000 (0
dec
)
80n2:14 User Calibration Cur-
rent Gain
Factor (without unit) REAL32 RW 0x3F800000
(1065353216
dec
)
80n2:15 User Calibration
Phase Offset
Value in milliseconds REAL32 RW 0x00000000 (0
dec
)
Index F800 PMX Settings
Index (hex) Name Meaning Data type Flags Default
F800:0 PMX Settings Max. subindex UINT8 RO 0x17 (23
dec
)
F800:01 Reset Interval Manual restart of the measurement and statistics in-
terval
BOOLEAN RW 0x00 (0
dec
)
F800:02 Enable Static Fund
Frequency
Fixation of the fundamental frequency for harmonic
calculation
BOOLEAN RW 0x00 (0
dez
)
F800:11 Reference Timing reference for the RMS calculation
Set to "Current" if a current is to be measured without
an applied voltage.
permitted values:
UINT32 RW 0x00000000 (0
dec
)
0 Voltage (default)
1 Current
F800:12 Measurement Range Filter setting for determining the fundamental
permitted values:
UINT32 RW 0x00000000 (0
dec
)
0 25..65 Hz (default)
1 25..400 Hz
2 12..45 Hz
F800:13 Frequency Source Source of the system frequency
permitted values:
BIT1 RW 0x00000000 (0
dec
)
0 Channel 1 (default)
1 Channel 2
2 Channel 3
F800:14 Power Calculation
Threshold
Noise reduction:
Here you can enter a minimum limit value in percent
for the power calculation, below which all values are
zeroed.
REAL32 RW 0x3F800000
(1065353216
dec
)
F800:15 Inaccurate Threshold
Voltage
Limit value for the warning bit: Inaccurate Voltage REAL32 RW 0x3FDC28F6
(1071393014
dec
)
F800:16 Inaccurate Threshold
Current
Limit value for the warning bit: Inaccurate Current REAL32 RW 0x3BC49BA6
(1002740646
dec
)
F800:17 Filter Length Filter length of the RMS value calculation:
0: Disable
1: 2 Samples
2: 3 Samples
3: 4 Samples
4: 5 Samples
5: 6 Samples
UINT32 RW Disable (0)
