Beckhoff EL34 Series User Manual

Commissioning
EL34xx 219Version: 1.5
Index 60n8 PMX Statistic Voltage (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n8:0 PMX Statistic Voltage Max Subindex UINT8 RO 0x13 (19
dec
)
60n8:11 Voltage Peak Peak value of the instantaneous voltage in the last in-
terval in V
REAL32 RO 0x00000000 (0
dec
)
60n8:12 Voltage RMS Mini-
mum
Minimum RMS value of the voltage in the last interval
in V
REAL32 RO 0x00000000 (0
dec
)
60n8:13 Voltage RMS Maxi-
mum
Maximum RMS value of the voltage in the last inter-
val in V
REAL32 RO 0x00000000 (0
dec
)
Index 60n9 PMX Statistic Current (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n9:0 PMX Statistic Current Max Subindex UINT8 RO 0x13 (19
dec
)
60n9:11 Current Peak Peak value of the instantaneous current in the last in-
terval in A
REAL32 RO 0x00000000 (0
dec
)
60n9:12 Current RMS Mini-
mum
Minimum RMS value of the current in the last interval
in A
REAL32 RO 0x00000000 (0
dec
)
60n9:13 Current RMS Maxi-
mum
Maximum RMS value of the current in the last inter-
val in A
REAL32 RO 0x00000000 (0
dec
)
Index 60nA PMX Statistic Power (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60nA:0 PMX Statistic Power Max Subindex UINT8 RO 0x19 (25
dec
)
60nA:11 Active Power Avg Average active power during the last interval in W REAL32 RO 0x00000000 (0
dec
)
60nA:12 Active Power Min Minimum active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
60nA:13 Active Power Max Maximum active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
60nA:14 Apparent Power Avg Average apparent power during the last interval in VA REAL32 RO 0x00000000 (0
dec
)
60nA:15 Apparent Power Max Maximum apparent power in the last interval in VA REAL32 RO 0x00000000 (0
dec
)
60nA:16 Reactive Power Avg Average reactive power average during the last inter-
val in var
REAL32 RO 0x00000000 (0
dec
)
60nA:17 Reactive Power Min Minimum reactive power in the last interval in var REAL32 RO 0x00000000 (0
dec
)
60nA:18 Reactive Power Max Maximum reactive power in the last interval in var REAL32 RO 0x00000000 (0
dec
)
60nA:19 Apparent Power Min Minimum apparent power in the last interval in VA REAL32 RO 0x00000000 (0
dec
)
Index 60nB PMX Classic (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
600B:0 PMX Classic Max. subindex UINT8 RO 0x16 (22
dec
)
600B:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00 (0
dec
)
600B:11 Voltage RMS value of the voltage in 0.001V INT32 RO 0x00000000 (0
dec
)
600B:12 Current RMS value of the current in 0.0001A INT32 RO 0x00000000 (0
dec
)
600B:13 Frequency Frequency of the fundamental in 0.001Hz INT32 RO 0x00000000 (0
dec
)
600B:14 Active Power Active power in 0.001W INT32 RO 0x00000000 (0
dec
)
600B:15 Apparent Power Apparent power in 0.001VA INT32 RO 0x00000000 (0
dec
)
600B:16 Reactive Power Reactive power in 0.001var INT32 RO 0x00000000 (0
dec
)
