Beckhoff EL34 Series User Manual

Commissioning
EL34xx 221Version: 1.5
Index F603 PMX Total Active
Index (hex) Name Meaning Data type Flags Default
F603:0 PMX Total Active Max. subindex UINT8 RO 0x14 (20
dec
)
F603:11 Active Power Active power in W INT64 RO
F603:12 Active Energy Recorded active energy in mWh INT64 RO
F603:13 Active Positive Energy Received active energy in mWh INT64 RO
F603:14 Active Negative En-
ergy
Supplied active energy in mWh INT64 RO
Index F604 PMX Total Active Fundamental
Index (hex) Name Meaning Data type Flags Default
F604:0 PMX Total Active
Fundamental
Max. subindex UINT8 RO 0x14 (20
dec
)
F604:11 Active Power Fund Active power of the fundamental oscillation in W INT64 RO
F604:12 Active Energy Fund Balanced active energy fundamental oscillation in
mWh
INT64 RO
F604:13 Active Positive En-
ergy Fund
Related active energy of the fundamental oscillation
in mWh
INT64 RO
F604:14 Active Negative En-
ergy Fund
Active energy fed into the system of the fundamental
oscillation in mWh
INT64 RO
Index F605 PMX Total Apparent
Index (hex) Name Meaning Data type Flags Default
F605:0 PMX Total Apparent Max. subindex UINT8 RO 0x14 (20
dec
)
F605:11 Apparent Power Balanced apparent power in VA INT64 RO
F605:12 Apparent Energy Recorded apparent energy in mWh INT64 RO
F605:13 Apparent Positive En-
ergy
Received apparent energy in mWh UINT64 RO
F605:14 Apparent Negative
Energy
Supplied apparent energy in mWh UINT64 RO
Index F606 PMX Total Apparent Fundamental
Index (hex) Name Meaning Data type Flags Default
F606:0 PMX Total Apparent
Fundamental
Max. subindex UINT8 RO 0x14 (20
dec
)
F606:11 Apparent Power Fund Apparent power fundamental in VA INT64 RO
F606:12 Apparent Energy Recorded apparent energy in mWh INT64 RO
F606:13 Apparent Positive En-
ergy
Received apparent energy in mWh UINT64 RO
F606:14 Apparent Negative
Energy
Supplied apparent energy in mWh UINT64 RO
Index F607 PMX Total Reactive
Index (hex) Name Meaning Data type Flags Default
F607:0 PMX Total Reactive Max. subindex UINT8 RO 0x14 (20
dec
)
F607:11 Reactive Power Balanced reactive power in Var INT64 RO
F607:12 Reactive Energy Recorded reactive energy in mWh INT64 RO
F607:13 Reactive Positive En-
ergy
Received reactive energy in mWh UINT64 RO
F607:14 Reactive Negative
Energy
Supplied reactive energy in mWh UINT64 RO
