Index F608 PMX Total Reactive Fundamental
Index (hex) Name Meaning Data type Flags Default
F608:0 PMX Total Reactive
Fundamental
Max. subindex UINT8 RO 0x14 (20
dec
)
F608:11 Reactive Power Fund Balanced reactive power of the fundamental oscilla-
tion in Var
INT64 RO
F608:12 Reactive Energy Recorded reactive energy in mWh INT64 RO
F608:13 Reactive Positive En-
ergy
Received reactive energy in mWh UINT64 RO
F608:14 Reactive Negative
Energy
Supplied reactive energy in mWh UINT64 RO
Index F609 PMX Total L-L Voltages
Index (hex) Name Meaning Data type Flags Default
F609:0 PMX Total L-L Volt-
ages
Max. subindex UINT8 RO 0x13 (19
dec
)
F609:11 L1-L2 Voltage RMS value of the phase-to-phase voltage between
L1 and L2 in V
REAL32 RO 0x00000000 (0
dec
)
F609:12 L2-L3 Voltage RMS value of the phase-to-phase voltage between
L2 and L3 in V
REAL32 RO 0x00000000 (0
dec
)
F609:13 L3-L1 Voltage RMS value of the phase-to-phase voltage between
L3 and L1 in V
REAL32 RO 0x00000000 (0
dec
)
Index F60A PMX Variant Value In
Index (hex) Name Meaning Data type Flags Default
F60A:0 PMX Variant Value In Max. subindex UINT8 RO 0x18 (24
dec
)
F60A:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00 (0
dec
)
F60A:11 Index 1 REAL Acknowledge for variable output value 1 UINT16 RO 0x0000 (0
dec
)
F60A:12 Value 1 REAL variable output value channel 1 REAL32 RO 0x00000000 (0
dec
)
F60A:13 Index 2 REAL Acknowledge for variable output value 2 UINT16 RO 0x0000 (0
dec
)
F60A:14 Value 2 REAL variable output value channel 2 REAL32 RO 0x00000000 (0
dec
)
F60A:15 Index 3 REAL Acknowledge for variable output value 3 UINT16 RO 0x0000 (0
dec
)
F60A:16 Value 3 REAL variable output value channel 3 REAL32 RO 0x00000000 (0
dec
)
F60A:17 Index 4 ULINT Acknowledge for variable output value 4 UINT16 RO 0x0000 (0
dec
)
F60A:18 Value 4 ULINT variable output value channel 4 UINT64 RO
Index F60B PMX Total Statistic Power
Index (hex) Name Meaning Data type Flags Default
F60B:0 PMX Total Statistic
Power
Max. subindex UINT8 RO 0x19 (25
dec
)
F60B:11 Active Power Avg Average total active power during the last interval in
W
REAL32 RO 0x00000000 (0
dec
)
F60B:12 Active Power Min Minimum total active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
F60B:13 Active Power Max Maximum total active power in the last interval in W REAL32 RO 0x00000000 (0
dec
)
F60B:14 Apparent Power Avg Average total apparent power during the last interval
in VA
REAL32 RO 0x00000000 (0
dec
)
F60B:15 Apparent Power Min Minimum total apparent power in the last interval in
VA
REAL32 RO 0x00000000 (0
dec
)
F60B:16 Apparent Power Max Maximum total apparent power in the last interval in
VA
REAL32 RO 0x00000000 (0
dec
)
F60B:17 Reactive Power Avg Average total reactive power average during the last
interval in Var
REAL32 RO 0x00000000 (0
dec
)
F60B:18 Reactive Power Min Minimum total reactive power in the last interval in
Var
REAL32 RO 0x00000000 (0
dec
)
F60B:19 Reactive Power Max Maximum total reactive power in the last interval in
Var
REAL32 RO 0x00000000 (0
dec
)
