Commissioning

EL34xx 235Version: 1.5

Index 1A24 Total TxPDO-Map Status

Index (hex) Name Meaning Data type Flags Default

1A24:0 Total TxPDO-Map

Status

PDO Mapping TxPDO 31 UINT8 RO 0x10 (16

dec

)

1A24:01 SubIndex 001 1. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x01 (System State))

UINT32 RO 0xF600:01, 1

1A24:02 SubIndex 002 2. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x02 (Grid Direction))

UINT32 RO 0xF600:02, 1

1A24:03 SubIndex 003 3. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x03 (Frequency Guard Warning))

UINT32 RO 0xF600:03, 1

1A24:04 SubIndex 004 4. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x04 (Frequency Guard Error))

UINT32 RO 0xF600:04, 1

1A24:05 SubIndex 005 5. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x05 (Neutral Current Guard Warning))

UINT32 RO 0xF600:05, 1

1A24:06 SubIndex 006 6. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x06 (Neutral Current Guard Error))

UINT32 RO 0xF600:06, 1

1A24:07 SubIndex 007 7. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x07 (Active Power Guard Warning))

UINT32 RO 0xF600:07, 1

1A24:08 SubIndex 008 8. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x08 (Active Power Guard Error))

UINT32 RO 0xF600:08, 1

1A24:09 SubIndex 009 9. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x09 (Apparent Power Guard Warn-

ing))

UINT32 RO 0xF600:09, 1

1A24:0A SubIndex 010 10. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x0A (Apparent Power Guard Error))

UINT32 RO 0xF600:0A, 1

1A24:0B SubIndex 011 11. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x0B (Power Quality Guard Warning))

UINT32 RO 0xF600:0B, 1

1A24:0C SubIndex 012 12. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x0C (Power Quality Guard Error))

UINT32 RO 0xF600:0C, 1

1A24:0D SubIndex 013 13. PDO Mapping entry (2 bits align) UINT32 RO 0x0000:00, 2

1A24:0E SubIndex 014 14. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x0F (TxPDO State))

UINT32 RO 0xF600:0F, 1

1A24:0F SubIndex 015 15. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x10 (TxPDO Toggle))

UINT32 RO 0xF600:10, 1

1A24:10 SubIndex 016 16. PDO Mapping entry (object 0xF600 (PMX Total

Status), entry 0x11 (Power Quality Factor))

UINT32 RO 0xF600:11, 32

Index 1A26 Total TxPDO-Map Advanced

Index (hex) Name Meaning Data type Flags Default

1A26:0 Total TxPDO-Map Ad-

vanced

PDO Mapping TxPDO 33 UINT8 RO 0x08 (8

dec

)

1A26:01 SubIndex 001 1. PDO Mapping entry (object 0xF602 (PMX Grid Ad-

vanced), entry 0x11 (Max Voltage Harmonic Distor-

tion))

UINT32 RO 0xF602:01, 1

1A26:02 SubIndex 002 2. PDO Mapping entry (object 0xF602 (PMX Grid Ad-

vanced), entry 0x12 (Max Current Harmonic Distor-

tion))

UINT32 RO 0xF602:02, 1

1A26:03 SubIndex 003 3. PDO Mapping entry (object 0xF602 (PMX Grid Ad-

vanced), entry 0x13 (Max Current Distortion Factor))

UINT32 RO 0x0000:00, 13

1A26:04 SubIndex 004 4. PDO Mapping entry (object 0xF602 (PMX Grid Ad-

vanced), entry 0x14 (Voltage Unbalance))

UINT32 RO 0xF602:10, 1

1A26:05 SubIndex 005 5. PDO Mapping entry (object 0xF602 (PMX Total

Advanced), entry 0x11 (Max Voltage Harmonic Dis-

tortion))

UINT32 RO 0xF602:11, 32

1A26:06 SubIndex 006 6. PDO Mapping entry (object 0xF602 (PMX Total

Advanced), entry 0x12 (Max Current Harmonic Dis-

tortion))

UINT32 RO 0xF602:12, 32

1A26:07 SubIndex 007 7. PDO Mapping entry (object 0xF602 (PMX Total

Advanced), entry 0x13 (Max Current Distortion Fac-

tor))

UINT32 RO 0xF602:13, 32

1A26:08 SubIndex 008 8. PDO Mapping entry (object 0xF602 (PMX Total

Advanced), entry 0x14 (Voltage Unbalance))

UINT32 RO 0xF602:14, 32
