Commissioning
EL34xx236 Version: 1.5
Index 1A27 Total TxPDO-Map Active
Index (hex) Name Meaning Data type Flags Default
1A27:0 Total TxPDO-Map Ac-
tive
PDO Mapping TxPDO 34 UINT8 RO 0x04 (4
dec
)
1A27:01 SubIndex 001 1. PDO Mapping entry (32 bits align) UINT32 RO 0x0000:00, 32
1A27:02 SubIndex 002 2. PDO Mapping entry (object 0xF603 (PMX Total
Active), entry 0x12 (Active Energy))
UINT32 RO 0xF603:12, 64
1A27:03 SubIndex 003 3. PDO Mapping entry (object 0xF603 (PMX Total
Active), entry 0x13 (Active Positive Energy))
UINT32 RO 0xF603:13, 64
1A27:04 SubIndex 004 4. PDO Mapping entry (object 0xF603 (PMX Total
Active), entry 0x14 (Active Negative Energy))
UINT32 RO 0xF603:14, 64
Index 1A28 Total TxPDO-Map Active Fundamental
Index (hex) Name Meaning Data type Flags Default
1A28:0 Total TxPDO-Map Ac-
tive Fundamental
PDO Mapping TxPDO 34 UINT8 RO 0x04 (4
dez
)
1A28:01 SubIndex 001 1. PDO Mapping entry (object 0xF604 (PMX Total
Active Fundamental), entry 0x11 (Active Power
Fund))
UINT32 RO 0xF604:11, 32
1A28:02 SubIndex 002 2. PDO Mapping entry (object 0xF604 (PMX Total
Active Fundamental), entry 0x12 (Active Energy
Fund))
UINT32 RO 0xF604:12, 64
1A28:03 SubIndex 003 3. PDO Mapping entry (object 0xF604 (PMX Total
Active Fundamental), entry 0x13 (Active Positive En-
ergy Fund))
UINT32 RO 0xF604:13, 64
1A28:04 SubIndex 004 4. PDO Mapping entry (object 0xF604 (PMX Total
Active Fundamental), entry 0x14 (Active Negative
Energy Fund))
UINT32 RO 0xF604:14, 64
Index 1A29 Total TxPDO-Map Apparent
Index (hex) Name Meaning Data type Flags Default
1A29:0 Total TxPDO-Map Ap-
parent
PDO Mapping TxPDO 35 UINT8 RO 0x04 (4
dec
)
1A29:01 SubIndex 001 1. PDO Mapping entry (32 bits align) UINT32 RO 0x0000:00, 32
1A29:02 SubIndex 002 2. PDO Mapping entry (object 0xF605 (PMX Total
Apparent), entry 0x12 (Apparent Energy))
UINT32 RO 0xF605:12, 64
1A29:03 SubIndex 003 3. PDO Mapping entry (object 0xF605 (PMX Total
Apparent), entry 0x13 (Apparent Positive Energy))
UINT32 RO 0xF605:13, 64
1A29:04 SubIndex 004 4. PDO Mapping entry (object 0xF605 (PMX Total
Apparent), entry 0x14 (Apparent Negative Energy))
UINT32 RO 0xF605:14, 64
Index 1A2A Total TxPDO-Map Apparent Fundamental
Index (hex) Name Meaning Data type Flags Default
1A2A:0 Total TxPDO-Map Ap-
parent Fundamental
PDO Mapping TxPDO 35 UINT8 RO 0x04 (4
dez
)
1A2A:01 SubIndex 001 1. PDO Mapping entry (object 0xF606 (PMX Total
Apparent Fundamental), entry 0x11 (Apparent Power
Fund))
UINT32 RO 0xF606:11, 32
1A2A:02 SubIndex 002 2. PDO Mapping entry (object 0xF606 (PMX Total
Apparent Fundamental), entry 0x12 (Apparent En-
ergy Fund))
UINT32 RO 0xF606:12, 64
1A2A:03 SubIndex 003 3. PDO Mapping entry (object 0xF606 (PMX Total
Apparent Fundamental), entry 0x13 (Apparent Posi-
tive Energy Fund))
UINT32 RO 0xF606:13, 64
1A2A:04 SubIndex 004 4. PDO Mapping entry (object 0xF606 (PMX Total
Apparent Fundamental), entry 0x14 (Apparent Nega-
tive Energy Fund))
UINT32 RO 0xF606:14, 64
