Commissioning
EL34xx 237Version: 1.5
Index 1A2B Total TxPDO-Map Reactive
Index (hex) Name Meaning Data type Flags Default
1A2B:0 Total TxPDO-Map
Reactive
PDO Mapping TxPDO 36 UINT8 RO 0x04 (4
dez
)
1A2B:01 SubIndex 001 1. PDO Mapping entry (object 0xF607 (PMX Total
Reactive), entry 0x11 (Reactive Power))
UINT32 RO 0xF607:11, 32
1A2B:02 SubIndex 002 2. PDO Mapping entry (object 0xF607 (PMX Total
Reactive), entry 0x12 (Reactive Energy))
UINT32 RO 0xF607:12, 64
1A2B:03 SubIndex 003 3. PDO Mapping entry (object 0xF607 (PMX Total
Reactive), entry 0x13 (Reactive Positive Energy))
UINT32 RO 0xF607:13, 64
1A2B:04 SubIndex 004 4. PDO Mapping entry (object 0xF607 (PMX Total
Reactive), entry 0x14 (Reactive Negative Energy))
UINT32 RO 0xF607:14, 64
Index 1A2C Total TxPDO-Map Reactive
Index (hex) Name Meaning Data type Flags Default
1A2C:0 Total TxPDO-Map
Reactive Fundamen-
tal
PDO Mapping TxPDO 36 UINT8 RO 0x04 (4
dec
)
1A2C:01 SubIndex 001 1. PDO Mapping entry (object 0xF608 (PMX Total
Reactive Fundamental), entry 0x11 (Reactive Power
Fund))
UINT32 RO 0xF608:11, 32
1A2C:02 SubIndex 002 2. PDO Mapping entry (object 0xF608 (PMX Total
Reactive Fundamental), entry 0x12 (Reactive Energy
Fund))
UINT32 RO 0xF608:12, 64
1A2C:03 SubIndex 003 3. PDO Mapping entry (object 0xF608 (PMX Total
Reactive Fundamental), entry 0x13 (Reactive Posi-
tive Energy Fund))
UINT32 RO 0xF608:13, 64
1A2C:04 SubIndex 004 4. PDO Mapping entry (object 0xF608 (PMX Total
Reactive Fundamental), entry 0x14 (Reactive Nega-
tive Energy Fund))
UINT32 RO 0xF608:14, 64
Index 1A2D Total TxPDO-Map L-L Voltage
Index (hex) Name Meaning Data type Flags Default
1A2D:0 Total TxPDO-Map L-L
Voltage
PDO Mapping TxPDO 37 UINT8 RO 0x03 (3
dez
)
1A2D:01 SubIndex 001 1. PDO Mapping entry (object 0xF609 (PMX Total L-
L Voltages), entry 0x11 (L1-L2 Voltage))
UINT32 RO 0xF609:11, 32
1A2D:02 SubIndex 002 2. PDO Mapping entry (object 0xF609 (PMX Total L-
L Voltages), entry 0x12 (L2-L3 Voltage))
UINT32 RO 0xF609:12, 32
1A2D:03 SubIndex 003 3. PDO Mapping entry (object 0xF609 (PMX Total L-
L Voltages), entry 0x13 (L3-L1 Voltage))
UINT32 RO 0xF609:13, 32
