Commissioning
EL34xx238 Version: 1.5
Index 1A2E Total TxPDO-Map Variant Value In
Index (hex) Name Meaning Data type Flags Default
1A2E:0 Total TxPDO-Map
Variant Value In
PDO Mapping TxPDO 38 UINT8 RO 0x0A (10
dec
)
1A2E:01 SubIndex 001 1. PDO Mapping entry (15 bits align) UINT32 RO 0x0000:00, 15
1A2E:02 SubIndex 002 2. PDO Mapping entry (object 0xF60A (PMX Variant
Value In), entry 0x10 (TxPDO Toggle))
UINT32 RO 0xF60A:10, 1
1A2E:03 SubIndex 003 3. PDO Mapping entry (object 0xF60A (PMX Variant
Value In), entry 0x11 (Index 1 REAL))
UINT32 RO 0xF60A:11, 16
1A2E:04 SubIndex 004 4. PDO Mapping entry (object 0xF60A (PMX Variant
Value In), entry 0x12 (Value 1 REAL))
UINT32 RO 0xF60A:12, 32
1A2E:05 SubIndex 005 5. PDO Mapping entry (object 0xF60A (PMX Variant
Value In), entry 0x13 (Index 2 REAL))
UINT32 RO 0xF60A:13, 16
1A2E:06 SubIndex 006 6. PDO Mapping entry (object 0xF60A (PMX Variant
Value In), entry 0x14 (Value 2 REAL))
UINT32 RO 0xF60A:14, 32
1A2E:07 SubIndex 007 7. PDO Mapping entry (object 0xF60A (PMX Variant
Value In), entry 0x13 (Index 3 REAL))
UINT32 RO 0xF60A:15, 16
1A2E:08 SubIndex 008 8. PDO Mapping entry (object 0xF60A (PMX Variant
Value In), entry 0x16 (Value 3 REAL))
UINT32 RO 0xF60A:16, 32
1A2E:09 SubIndex 009 9. PDO Mapping entry (object 0xF60A (PMX Variant
Value In), entry 0x17 (Index 4 ULINT))
UINT32 RO 0xF60A:17, 16
1A2E:0A SubIndex 010 10. PDO Mapping entry (object 0xF60A (PMX Variant
Value In), entry 0x18 (Value 4 ULINT))
UINT32 RO 0xF60A:18, 64
Index 1A2F Total TxPDO-Map Statistic Power
Index (hex) Name Meaning Data type Flags Default
1A2F:0 Total TxPDO-Map
Statistic Power
PDO Mapping TxPDO 39 UINT8 RO 0x09 (9
dec
)
1A2F:01 SubIndex 001 1. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x11 (Active Power Avg))
UINT32 RO 0xF60B:11, 32
1A2F:02 SubIndex 002 2. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x12 (Active Power Min))
UINT32 RO 0xF60B:12, 32
1A2F:03 SubIndex 003 3. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x13 (Active Power Max))
UINT32 RO 0xF60B:13, 32
1A2F:04 SubIndex 004 4. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x14 (Apparent Power Avg))
UINT32 RO 0xF60B:14, 32
1A2F:05 SubIndex 005 5. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x15 (Apparent Power Min))
UINT32 RO 0xF60B:15, 32
1A2F:06 SubIndex 006 6. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x16 (Apparent Power Max))
UINT32 RO 0xF60B:16, 32
1A2F:07 SubIndex 007 7. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x17 (Reactive Power Avg))
UINT32 RO 0xF60B:17, 32
1A2F:08 SubIndex 008 8. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x18 (Reactive Power Min))
UINT32 RO 0xF60B:18, 32
1A2F:09 SubIndex 009 9. PDO Mapping entry (object 0xF60B (PMX Total
Statistic Power), entry 0x19 (Reactive Power Max))
UINT32 RO 0xF60B:19, 32
Index 1A30 Total TxPDO-Map Statistic PQF
Index (hex) Name Meaning Data type Flags Default
1A30:0 Total TxPDO-Map
Statistic PQF
PDO Mapping TxPDO 40 UINT8 RO 0x03 (3
dec
)
1A30:01 SubIndex 001 1. PDO Mapping entry (object 0xF60C (PMX Total
Statistic PQF), entry 0x11 (PQF Avg))
UINT32 RO 0xF60C:11, 32
1A30:02 SubIndex 002 2. PDO Mapping entry (object 0xF60C (PMX Total
Statistic PQF), entry 0x12 (PQF Min))
UINT32 RO 0xF60C:12, 32
1A30:03 SubIndex 003 3. PDO Mapping entry (object 0xF60C (PMX Total
Statistic PQF), entry 0x13 (PQF Max))
UINT32 RO 0xF60C:13, 32
