Commissioning

EL34xx 239Version: 1.5

Index 1A31 Total TxPDO-Map Interval Energy

Index (hex) Name Meaning Data type Flags Default

1A31:0 Total TxPDO-Map In-

terval Energy

PDO Mapping TxPDO 41 UINT8 RO 0x0B (11

dec

)

1A31:01 SubIndex 001 1. PDO Mapping entry (15 bits align) UINT32 RO 0x0000:00, 15

1A31:02 SubIndex 002 2. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x10 (TxPDO Toggle))

UINT32 RO 0xF60D:10, 1

1A31:03 SubIndex 003 3. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x11 (Active Energy))

UINT32 RO 0xF60D:11, 32

1A31:04 SubIndex 004 4. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x12 (Active Energy Positive))

UINT32 RO 0xF60D:12, 32

1A31:05 SubIndex 005 5. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x13 (Active Energy Negative))

UINT32 RO 0xF60D:13, 32

1A31:06 SubIndex 006 6. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x14 (Apparent Energy))

UINT32 RO 0xF60D:14, 32

1A31:07 SubIndex 007 7. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x15 (Apparent Energy Posi-

tive))

UINT32 RO 0xF60D:15, 32

1A31:08 SubIndex 008 8. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x16 (Apparent Energy Nega-

tive))

UINT32 RO 0xF60D:16, 32

1A31:09 SubIndex 009 9. PDO Mapping entry (object 0xF60D (PMX Total In-

terval Energy), entry 0x17 (Reactive Energy))

UINT32 RO 0xF60D:17, 32

1A31:0A SubIndex 010 10. PDO Mapping entry (object 0xF60D (PMX Total

Interval Energy), entry 0x18 (Reactive Energy Posi-

tive))

UINT32 RO 0xF60D:18, 32

1A31:0B SubIndex 011 11. PDO Mapping entry (object 0xF60D (PMX Total

Interval Energy), entry 0x19 (Reactive Energy Nega-

tive))

UINT32 RO 0xF60D:19, 32

Index 1A32 Total TxPDO-Map Interval Energy Fundamental

Index (hex) Name Meaning Data type Flags Default

1A32:0 Total TxPDO-Map In-

terval Energy Funda-

mental

PDO Mapping TxPDO 41 UINT8 RO 0x0B (11

dez

)

1A32:01 SubIndex 001 1. PDO Mapping entry (15 bits align) UINT32 RO 0x0000:00, 15

1A32:02 SubIndex 002 2. PDO Mapping entry (object 0xF60E (PMX Total In-

terval Energy Fundamental), entry 0x10 (TxPDO

Toggle Fund))

UINT32 RO 0xF60E:10, 1

1A32:03 SubIndex 003 3. PDO Mapping entry (object 0xF60E (PMX Total In-

terval Energy Fundamental), entry 0x11 (Active En-

ergy Fund))

UINT32 RO 0xF60E:11, 32

1A32:04 SubIndex 004 4. PDO Mapping entry (object 0xF60E (PMX Total In-

terval Energy Fundamental), entry 0x12 (Active En-

ergy Positive Fund))

UINT32 RO 0xF60E:12, 32

1A32:05 SubIndex 005 5. PDO Mapping entry (object 0xF60E (PMX Total In-

terval Energy Fundamental), entry 0x13 (Active En-

ergy Negative Fund))

UINT32 RO 0xF60E:13, 32

1A32:06 SubIndex 006 6. PDO Mapping entry (object 0xF60E (PMX Total In-

terval Energy Fundamental), entry 0x14 (Apparent

Energy Fund))

UINT32 RO 0xF60E:14, 32

1A32:07 SubIndex 007 7. PDO Mapping entry (object 0xF60E (PMX Total In-

terval Energy Fundamental), entry 0x15 (Apparent

Energy Positive Fund))

UINT32 RO 0xF60E:15, 32

1A32:08 SubIndex 008 8. PDO Mapping entry (object 0xF60E (PMX Total In-

terval Energy Fundamental), entry 0x16 (Apparent

Energy Negative Fund))

UINT32 RO 0xF60E:16, 32

1A32:09 SubIndex 009 9. PDO Mapping entry (object 0xF60E (PMX Total In-

terval Energy Fundamental), entry 0x17 (Reactive

Energy Fund))

UINT32 RO 0xF60E:17, 32

1A32:0A SubIndex 010 10. PDO Mapping entry (object 0xF60E (PMX Total

Interval Energy Fundamental), entry 0x18 (Reactive

Energy Positive Fund))

UINT32 RO 0xF60E:18, 32

1A32:0B SubIndex 011 11. PDO Mapping entry (object 0xF60E (PMX Total

Interval Energy Fundamental), entry 0x19 (Reactive

Energy Negative Fund))

UINT32 RO 0xF60E:19, 32
