Commissioning
EL34xx240 Version: 1.5
Index 1A33 Total TxPDO-Map System Angles
Index (hex) Name Meaning Data type Flags Default
1A33:0 Total TxPDO-Map
System Angles
PDO Mapping TxPDO 41 UINT8 RO 0x05 (5
dez
)
1A33:01 SubIndex 001 1. PDO Mapping entry (object 0xF60F (PMX Total
System Angles), entry 0x11 (Voltage Angle L1L2))
UINT32 RO 0xF60F:11, 32
1A33:02 SubIndex 002 2. PDO Mapping entry (object 0xF60F (PMX Total
System Angles), entry 0x12 (Voltage Angle L1L3))
UINT32 RO 0xF60F:12, 32
1A33:03 SubIndex 003 3. PDO Mapping entry (object 0xF60F (PMX Total
System Angles), entry 0x13 (Current Angle L1))
UINT32 RO 0xF60F:13, 32
1A33:04 SubIndex 004 4. PDO Mapping entry (object 0xF60F (PMX Total
System Angles), entry 0x14 (Current Angle L2))
UINT32 RO 0xF60F:14, 32
1A33:05 SubIndex 005 5. PDO Mapping entry (object 0xF60F (PMX Total
System Angles), entry 0x15 (Current Angle L3))
UINT32 RO 0xF60F:15, 32
Index 1A34 Total TxPDO-Map System
Index (hex) Name Meaning Data type Flags Default
1A34:0 Total TxPDO-Map
System
PDO Mapping TxPDO 41 UINT8 RO 0x03 (3
dez
)
1A34:01 SubIndex 001 1. PDO Mapping entry (object 0xF610 (PMX Total
System ), entry 0x11 (Positive Sequence))
UINT32 RO 0xF610:11, 32
1A34:02 SubIndex 002 2. PDO Mapping entry (object 0xF610 (PMX Total
System ), entry 0x12 (Negative Sequence))
UINT32 RO 0xF610:12, 32
1A34:03 SubIndex 003 3. PDO Mapping entry (object 0xF610 (PMX Total
System ), entry 0x13 (Zero Sequence))
UINT32 RO 0xF610:13, 32
Index 1A35 Total TxPDO-Map Statistic Power Fundamental
Index (hex) Name Meaning Data type Flags Default
1A35:0 Total TxPDO-Map
Statistic Power Fun-
damental
PDO Mapping TxPDO 39 UINT8 RO 0x09 (9
dez
)
1A35:01 SubIndex 001 1. PDO Mapping entry (object 0xF611 (PMX Total
Statistic Power Fundamental), entry 0x10 (Active
Power Avg Fund))
UINT32 RO 0xF611:10, 32
1A35:02 SubIndex 002 2. PDO Mapping entry (object 0xF611 (PMX Total
Statistic Power Fundamental), entry 0x11 (Active
Power Min Fund))
UINT32 RO 0xF611:11, 32
1A35:03 SubIndex 003 3. PDO Mapping entry (object 0xF611 (PMX Total
Statistic Power Fundamental), entry 0x12 (Active
Power Max Fund))
UINT32 RO 0xF611:12, 32
1A35:04 SubIndex 004 4. PDO Mapping entry (object 0xF611 (PMX Total
Statistic Power Fundamental), entry 0x13 (Apparent
Power Avg Fund))
UINT32 RO 0xF611:13, 32
1A35:05 SubIndex 005 5. PDO Mapping entry (object 0xF611 (PMX Total
Statistic Power Fundamental), entry 0x14 (Apparent
Power Min Fund))
UINT32 RO 0xF611:14, 32
1A35:06 SubIndex 006 6. PDO Mapping entry (object 0xF611 (PMX Total
Statistic Power Fundamental), entry 0x15 (Apparent
Power Max Fund))
UINT32 RO 0xF611:15, 32
1A35:07 SubIndex 007 7. PDO Mapping entry (object 0xF611 (PMX Total
Statistic Power Fundamental), entry 0x16 (Reactive
Power Avg Fund))
UINT32 RO 0xF611:16, 32
1A35:08 SubIndex 008 8. PDO Mapping entry (object 0xF611 (PMX Total
Statistic Power Fundamental), entry 0x17 (Reactive
Power Min))
UINT32 RO 0xF611:17, 32
1A35:09 SubIndex 009 9. PDO Mapping entry (object 0xF611 (PMX Total
Statistic Power Fundamental), entry 0x18 (Reactive
Power Max))
UINT32 RO 0xF611:18, 32
