Beckhoff EL34 Series User Manual

Commissioning
EL34xx 249Version: 1.5
Index F801 PMX Total Settings PQF
Index (hex) Name Meaning Data type Flags Default
F801:0 PMX Total Settings
PQF
Max. subindex UINT8 RO 0x13 (19
dec
)
F801:11 Nominal voltage A nominal voltage value or set value is required to
calculate the power quality factor (for details see ba-
sic function principles).
REAL32 RW 0x43660000
(1130758144
dec
)
F801:12 Nominal Frequency A nominal frequency or set value is required to calcu-
late the power quality factor (for details see basic
function principles).
REAL32 RW 0x42480000
(1112014848
dec
)
F801:13 PQF Dataset permitted values: UINT32 RW 0x00000001 (0
dec
)
0: default
1: default + unbalace
Index F802 PMX Guard Settings
Index (hex) Name Meaning Data type Flags Default
F802:0 PMX Guard Settings Max. subindex UINT8 RO 0x28 (40
dec
)
F802:11 Frequency Guard Min
Error
Lower limit value for a frequency error message REAL32 RW 0x423C0000
(1111228416
dec
)
F802:12 Frequency Guard Min
Warning
Lower limit value for a frequency warning message REAL32 RW 0x42460000
(1111883776
dec
)
F802:13 Frequency Guard
Max Warning
Upper limit value for a frequency warning message REAL32 RW 0x424A0000
(1112145920
dec
)
F802:14 Frequency Guard
Max Error
Upper limit value for a frequency error message REAL32 RW 0x42500000
(1112539136
dec
)
F802:21 PQF Guard Min Error Lower limit value for a power quality factor error mes-
sage
REAL32 RW 0x3D4CCCCD
(1028443341
dec
)
F802:22 PQF Guard Min
Warning
Lower limit value for a power quality factor warning
message
REAL32 RW 0x3F4CCCCD
(1061997773
dec
)
F802:23 PQF Guard Max
Warning
Upper limit value for a power quality factor warning
message
REAL32 RW 0x3F800000
(1065353216
dec
)
F802:24 PQF Guard Max Error Upper limit value for a power quality factor error mes-
sage
REAL32 RW 0x3F800000
(1065353216
dec
)
F802:25 Unbalance Guard Min
Error
Lower limit value for an error message due to voltage
imbalance
REAL32 RW 0x00000000 (0
dec
)
F802:26 Unbalance Guard Min
Warning
Lower limit value for a warning message due to volt-
age imbalance
REAL32 RW 0x00000000 (0
dec
)
F802:27 Unbalance Guard
Max Warning
Upper limit value for a warning message due to volt-
age imbalance
REAL32 RW 0x00000000 (0
dec
)
F802:28 Unbalance Guard
Max Error
Upper limit value for an error message due to voltage
imbalance
REAL32 RW 0x00000000 (0
dec
)
6.7.5.3 Configuration data (vendor-specific)
Index 80nF PMX vendor data (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
80nF:0 PMX Vendor data Max. subindex UINT8 RO 0x13 (19
dec
)
80nF:11 Calibration Voltage
Offset
Value in V REAL32 RW 0x00000000 (0
dec
)
80nF:12 Calibration Voltage
Gain
Factor (without unit) REAL32 RW 0x3F800000
(1065353216
dec
)
80nF:13 Calibration Voltage
Phase Offset
Value in milliseconds REAL32 RW 0x00000000 (0
dec
)
