Beckhoff EL34 Series User Manual

Commissioning
EL34xx250 Version: 1.5
6.7.5.4 Input data
Index 60n0 PMX status (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n0:0 PMX Status Max. subindex UINT8 RO 0x10 (16
dec
)
60n0:01 Voltage Sign Bit Indicates the sign of the current sine wave voltage:
1 = U > 0V
0 = U < 0V
BOOLEAN RO 0x00 (0
dec
)
60n0:02 Overvoltage Maximum measurable voltage is exceeded. BOOLEAN RO 0x00 (0
dec
)
60n0:03 Overcurrent Maximum measurable current is exceeded. BOOLEAN RO 0x00 (0
dec
)
60n0:04 Inaccurate Voltage The measured voltage value is smaller than the value
entered in CoE object "F800:15 Inaccurate Threshold
Voltage".
BOOLEAN RO 0x00 (0
dec
)
60n0:05 Inaccurate Current The measured current value is smaller than the value
entered in CoE object "F800:16 Inaccurate Threshold
Current".
BOOLEAN RO 0x00 (0
dec
)
60n0:06 Voltage Guard Warn-
ing
A warning limit of the voltage monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
60n0:07 Voltage Guard Error An error limit of the voltage monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
6000:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00 (0
dec
)
Index 60n1*** PMX Basic (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n1:0 PMX Basic Max. Subindex UINT8 RO 0x11 (17
dec
)
60n1:11 Voltage RMS value of the voltage in V REAL32 RO 0x00000000 (0
dec
)
