Beckhoff EL34 Series User Manual

Commissioning
EL34xx 251Version: 1.5
Index F600 PMX Total Status
Index (hex) Name Meaning Data type Flags Default
F600:0 PMX Total Status Max. subindex UINT8 RO 0x11 (17
dec
)
F600:01 System State Overall system state (as a logical disjunction of volt-
age guard errors, phase sequence, overvoltage,
overcurrent and frequency guard errors)
BOOLEAN RO 0x00 (0
dec
)
F600:02 Grid Direction Phase sequence L1 - L2 - L3 correctly detected (with
clockwise 3-phase mains)
BOOLEAN RO 0x00 (0
dec
)
F600:03 Frequency Guard
Warning
A warning limit of the frequency monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
F600:04 Frequency Guard Er-
ror
An error limit of the frequency monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
F600:05 Neutral Current Guard
Warning
A warning limit of the neutral conductor current moni-
tor has been breached.
BOOLEAN RO 0x00 (0
dec
)
F600:06 Neutral Current Guard
Error
An error limit of the neutral conductor current monitor
has been breached.
BOOLEAN RO 0x00 (0
dec
)
F600:07 Active Power Guard
Warning
A warning limit of the active power monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
F600:08 Active Power Guard
Error
An error limit of the active power monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
F600:09 Apparent Power
Guard Warning
A warning limit of the apparent power monitor has
been breached.
BOOLEAN RO 0x00 (0
dec
)
F600:0A Apparent Power
Guard Error
An error limit of the apparent power monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
F600:0B Power Quality Guard
Warning
A warning limit of the PQF monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
F600:0C Power Quality Guard
Error
An error limit of the PQF monitor has been breached. BOOLEAN RO 0x00 (0
dec
)
F600:0F TxPDO State TRUE for general error BOOLEAN RO 0x00 (0
dec
)
F600:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00 (0
dec
)
F600:11 Power Quality Factor Analog value of the voltage quality between 1.0 and
0 (see basic function principles - Power Quality Fac-
tor)
REAL32 RO 0x00000000 (0
dec
)
Index F602 PMX Total Advanced
Index (hex) Name Meaning Data type Flags Default
F602:0 PMX Total Advanced Max. subindex UINT8 RO 0x02 (2
dec
)
F602:01 Unbalance Guard
Warning
A warning limit of the unbalance monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
F602:02 Unbalance Guard Er-
ror
An error limit of the unbalance monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
6.7.5.5 Information and diagnostic data
Index A0n0 PMX Diag data (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
A0n0:0 PMX diag data ch.1 Max. subindex UINT8 RO 0x11 (17
dec
)
A0n0:11 Saturation Time Volt-
age
Time (in 0.1 ms) in which the terminal has measured
an overvoltage.
UINT32 RO 0x00000000 (0
dec
)
Index F081 Download revision
Index (hex) Name Meaning Data type Flags Default
F081:0 Download revision Max. subindex UINT8 RO 0x01 (1
dec
)
F010:01 Revision number Configured revision of the terminal,
(see note)
UINT32 RW 0x00000000 (0
dec
)
