Beckhoff EL34 Series User Manual

Commissioning
EL34xx252 Version: 1.5
Index F80F PM Vendor data
Index (hex) Name Meaning Data type Flags Default
F80F:0 PMX Vendor data Max. subindex UINT8 RO 0x11 (17
dec
)
F80F:11 Type Vendor-specific data UINT32 RW 0x00000000 (0
dec
)
Index F904 PMX Total Info data PQF
Index (hex) Name Meaning Data type Flags Default
F904:0 PMX Total Info data
PQF
Max. subindex UINT8 RO 0x13 (19
dec
)
F904:11 PQF Avg Average value of the power quality factor during the
last interval
REAL32 RO 0x00000000 (0
dec
)
F904:12 PQF Min Minimum power quality factor in the last interval REAL32 RO 0x00000000 (0
dec
)
F904:13 PQF Max Maximum power quality factor in the last interval REAL32 RO 0x00000000 (0
dec
)
Index FA00 PMX Diag data
Index (hex) Name Meaning Data type Flags Default
FA00:0 PMX Diag data Max. subindex UINT8 RO 0x13 (19
dec
)
FA00:11 Min CPU Die Temper-
ature
Minimum CPU temperature measured so far REAL32 RO 0x00000000 (0
dec
)
FA00:12 Max CPU Die Tem-
perature
Maximum CPU temperature measured so far REAL32 RO 0x00000000 (0
dec
)
FA00:13 EBUS Voltage Current E-bus voltage REAL32 RO 0x00000000 (0
dec
)
6.7.5.6 Standard objects
Standard objects (0x1000-0x1FFF)
The standard objects have the same meaning for all EtherCAT slaves.
Index 1000 Device type
Index (hex) Name Meaning Data type Flags Default
1000:0 Device type Device type of the EtherCAT slave: The Lo-Word
contains the CoE profile used (5001). The Hi-Word
contains the module profile according to the modular
device profile.
UINT32 RO 0x01551389
(22352777
dec
)
Index 1008 Device name
Index (hex) Name Meaning Data type Flags Default
1008:0 Device name Device name of the EtherCAT slave STRING RO EL34xx
Index 1009 Hardware version
Index (hex) Name Meaning Data type Flags Default
1009:0 Hardware version Hardware version of the EtherCAT slave STRING RO
Index 100A Software Version
Index (hex) Name Meaning Data type Flags Default
100A:0 Software version Firmware version of the EtherCAT slave STRING RO
Index 100B Bootloader version
Index (hex) Name Meaning Data type Flags Default
100B:0 Bootloader version Bootloader version STRING RO
