Commissioning
EL34xx 253Version: 1.5
Index 1018 Identity
Index (hex) Name Meaning Data type Flags Default
1018:0 Identity Information for identifying the slave UINT8 RO 0x04 (4
dec
)
1018:01 Vendor ID Vendor ID of the EtherCAT slave UINT32 RO 0x00000002 (2
dec
)
1018:02 Product code Product code of the EtherCAT slave UINT32 RO 0x0D9B3052
(228274258
dec
)
1018:03 Revision Revision numberīof the EtherCAT slave; the low
word (bit 0-15) indicates the special terminal number,
the high word (bit 16-31) refers to the device descrip-
tion
UINT32 RO 0x00000000 (0
dec
)
1018:04 Serial number Serial number of the EtherCAT slave; the low byte
(bit 0-7) of the low word contains the year of produc-
tion, the high byte (bit 8-15) of the low word contains
the week of production, the high word (bit 16-31) is 0
UINT32 RO 0x00000000 (0
dec
)
Index 10F0 Backup parameter
Index (hex) Name Meaning Data type Flags Default
10F0:0 Backup parameter Length of this object UINT8 RO 0x01
10F0:01 Checksum Checksum UINT32 RW 0x00000000 (0
dec
)
Index 10F3 Diagnosis History
Index Name Meaning Data type Flags Default
10F3:0 Diagnosis History Maximum subindex UINT8 RO 0x15 (21
dec
)
10F3:01 Maximum Messages Maximum number of stored messages. A maximum
of 50 messages can be stored
UINT8 RO 0x00 (0
dec
)
10F3:02 Newest Message Subindex of the latest message UINT8 RO 0x00 (0
dec
)
10F3:03 Newest Acknowl-
edged Message
Subindex of the last confirmed message UINT8 RW 0x00 (0
dec
)
10F3:04 New Messages Avail-
able
Indicates that a new message is available BOOLEAN RO 0x00 (0
dec
)
10F3:05 Flags not used UINT16 RW 0x0000 (0
dec
)
10F3:06 Diagnosis Message
001
Message 1 OCTET
STRING[28]
RO {0}
... ... ... ... ... ...
10F3:15 Diagnosis Message
016
Message 16 OCTET
STRING[28]
RO {0}
Index 10F8 Actual Time Stamp
Index Name Meaning Data type Flags Default
10F8:0 Actual Time Stamp Time stamp UINT64 RO 0x00000000000000
00 (0
dec
)
