Commissioning
EL34xx254 Version: 1.5
Index 1App TxPDO-Map Status (for L1, pp = 00; L2, pp = 0A; L3, pp = 14)
Index (hex) Name Meaning Data type Flags Default
1App:0 TxPDO-Map Status PDO Mapping TxPDO UINT8 RO 0x09 (9
dec
)
1App:01 SubIndex 001 1. PDO Mapping entry (1 bits align) UINT32 RO 0x0000:00, 1
1App:02 SubIndex 002 2. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x02 (Overvoltage))
UINT32 RO 0x60n0:02, 1**
1App:03 SubIndex 003 3. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x03 (Overcurrent))
UINT32 RO 0x60n0:03, 1**
1App:04 SubIndex 004 4. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x04 (Inaccurate Voltage))
UINT32 RO 0x60n0:04, 1**
1App:05 SubIndex 005 5. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x05 (Inaccurate Current))
UINT32 RO 0x60n0:05, 1**
1App:06 SubIndex 006 6. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x06 (Voltage Guard Warning))
UINT32 RO 0x60n0:06, 1**
1App:07 SubIndex 007 7. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x07 (Voltage Guard Error))
UINT32 RO 0x60n0:07, 1**
1App:08 SubIndex 008 8. PDO Mapping entry (8 bits align) UINT32 RO 0x0000:00, 8**
1App:09 SubIndex 009 9. PDO Mapping entry (object 0x60n0 (PMX Status),
entry 0x10 (TxPDO Toggle))
UINT32 RO 0x60n0:10, 1**
**) for L1, n = 0; L2, n = 1; L3, n = 2)
Index 1A01*** L1 TxPDO-Map Status
Index (hex) Name Meaning Data type Flags Default
1A01:0 L1 TxPDO-Map Sta-
tus
PDO Mapping TxPDO UINT8 RO 0x01 (1
dec
)
1A01:01 SubIndex 001 1. PDO Mapping entry (object 0x6001 (PMX Basic),
entry 0x01 (Voltage))
UINT32 RO 0x6001:11, 32
***) only for EL3483-0060
Index 1A0B*** L2 TxPDO-Map Status
Index (hex) Name Meaning Data type Flags Default
1A0B:0 L2 TxPDO-Map Sta-
tus
PDO Mapping TxPDO UINT8 RO 0x01 (1
dec
)
1A0B:01 SubIndex 001 1. PDO Mapping entry (object 0x6011 (PMX Basic),
entry 0x01 (Voltage))
UINT32 RO 0x6011:11, 32
***) only for EL3483-0060
Index 1A15*** L3 TxPDO-Map Status
Index (hex) Name Meaning Data type Flags Default
1A15:0 L3 TxPDO-Map Sta-
tus
PDO Mapping TxPDO UINT8 RO 0x01 (1
dec
)
1A15:01 SubIndex 001 1. PDO Mapping entry (object 0x6021 (PMX Basic),
entry 0x01 (Voltage))
UINT32 RO 0x6021:11, 32
***) only for EL3483-0060
