Beckhoff EL34 Series User Manual

Commissioning
EL34xx258 Version: 1.5
Index F010 Module List
Index (hex) Name Meaning Data type Flags Default
F010:0 Module list UINT8 RW 0x03 (3
dec
)
F010:01 SubIndex 001 UINT32 RW 0x00000155 (341
dec
)
F010:02 SubIndex 002 UINT32 RW 0x00000155 (341
dec
)
F010:03 SubIndex 003 UINT32 RW 0x00000155 (341
dec
)
6.7.5.7 Command object
Index FB00 PMX Command
The command object is used for triggering an action in the terminal. The command is started by writing
subindex 1 (request). Write access is disabled until the current command is completed.
Index (hex) Name Meaning Data type Flags Default
FB00:0 PM Command Largest subindex of this object UINT8 RO 0x03
FB00:01 Request Byte 0 - service request data OCTET-
STRING [2]
RW 0x0000 (0
dec
)
4
hex
Clear energy
Byte 1 - channel selection
00
hex
all channels
01
hex
Channel 1
02
hex
Channel 2
03
hex
Channel 3
FB00:02 Status Byte 0 UINT8 RW 0x00 (0
dec
)
reserved
FB00:03 Response Byte 0 OCTET-
STRING [2]
RW 0x00000000 (0
dec
)
reserved
Byte 1
reserved
Byte 2-n
reserved
