Overview of CoE objects EL6001, EL6021

EL600x, EL602x 157Version: 4.6

Index

(hex)

Name Meaning Data type Flags Default

1A05:20 SubIndex 0x032 32. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x27 (Data In 22))

UINT32 RO 0x6001:27, 16

1A05:21 SubIndex 0x033 33. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x28 (Data In 23))

UINT32 RO 0x6001:28, 16

1A05:22 SubIndex 0x034 34. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x29 (Data In 24))

UINT32 RO 0x6001:29, 16

1A05:23 SubIndex 0x035 35. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x2A (Data In 25))

UINT32 RO 0x6001:2A, 16

1A05:24 SubIndex 0x036 36. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x2B (Data In 26))

UINT32 RO 0x6001:2B, 16

1A05:25 SubIndex 0x037 37. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x2C (Data In 27))

UINT32 RO 0x6001:2C, 16

1A05:26 SubIndex 0x038 38. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x2D (Data In 28))

UINT32 RO 0x6001:2D, 16

1A05:27 SubIndex 0x039 39. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x2E (Data In 29))

UINT32 RO 0x6001:2E, 16

1A05:28 SubIndex 0x040 40. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x2F (Data In 30))

UINT32 RO 0x6001:2F, 16

1A05:29 SubIndex 0x041 41. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x30 (Data In 31))

UINT32 RO 0x6001:30, 16

1A05:2A SubIndex 0x042 42. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x31 (Data In 32))

UINT32 RO 0x6001:31, 16

1A05:2B SubIndex 0x043 43. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x32 (Data In 33))

UINT32 RO 0x6001:32, 16

1A05:2C SubIndex 0x044 44. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x33 (Data In 34))

UINT32 RO 0x6001:33, 16

1A05:2D SubIndex 0x045 45. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x34 (Data In 35))

UINT32 RO 0x6001:34, 16

1A05:2E SubIndex 0x046 46. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x35 (Data In 36))

UINT32 RO 0x6001:35, 16

1A05:2F SubIndex 0x047 47. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x36 (Data In 37))

UINT32 RO 0x6001:36, 16

1A05:30 SubIndex 0x048 48. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x37 (Data In 38))

UINT32 RO 0x6001:37, 16

1A05:31 SubIndex 0x049 49. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x38 (Data In 39))

UINT32 RO 0x6001:38, 16

1A05:32 SubIndex 0x050 50. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x39 (Data In 40))

UINT32 RO 0x6001:39, 16

1A05:33 SubIndex 0x051 51. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x3A (Data In 41))

UINT32 RO 0x6001:3A, 16

1A05:34 SubIndex 0x052 52. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x3B (Data In 42))

UINT32 RO 0x6001:3B, 16

1A05:35 SubIndex 0x053 53. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x3C (Data In 43))

UINT32 RO 0x6001:3C, 16

1A05:36 SubIndex 0x054 54. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x3D (Data In 44))

UINT32 RO 0x6001:3D, 16

1A05:37 SubIndex 0x055 55. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x3E (Data In 45))

UINT32 RO 0x6001:3E, 16

1A05:38 SubIndex 0x056 56. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x3F (Data In 46))

UINT32 RO 0x6001:3F, 16

1A05:39 SubIndex 0x057 57. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x40 (Data In 47))

UINT32 RO 0x6001:40, 16

1A05:3A SubIndex 0x058 58. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x41 (Data In 48))

UINT32 RO 0x6001:41, 16

1A05:3B SubIndex 0x059 59. PDO Mapping entry (object 0x6001 (COM ext. in-

puts), entry 0x42 (Data In 49))

UINT32 RO 0x6001:42, 16
