Product overview
KL1xxx14 Version: 1.0.0
Four-channel, digital input terminals, 24V
DC
The KL1104 and KL1114 digital input terminals acquire the binary control signals from the process level and
transmit them, in an electrically isolated form, to the higher-level automation unit. The KL1104 and KL1114
versions have input filters of different speeds. The Bus Terminals contain four channels that indicate their
signal state by means of light emitting diodes.
2.3.1 KL1104, KL1114 – Technical data
Technical data KL1104, KS1104 KL1114, KS1114
Connection technology 2-wire / 3-wire
Specification EN 61131-2, type 1/3
Number of inputs 4
Nominal voltage 24V
DC
(-15%/+20%)
Signal voltage ‘0’ -3V to 5V (EN 61131-2, type 1)
Signal voltage ‘1’ 15V to 30V (EN 61131-2, type 1)
Input filter 3ms 0.2ms
Input current typical 5mA (EN 61131-2, type1)
Current consumption from K-bus typically 5mA
Electrical isolation 500V (K-bus / field voltage)
Bit width in process image 4 input bits
Configuration no address or configuration settings required
Weight approx. 55g
Permissible ambient temperature
during operation
-25°C ... +60°C (extended temperature range)
Permissible ambient temperature
during storage
-40°C ... +85°C
Permissible relative humidity 95%, no condensation
Vibration / shock resistance according to EN 60068-2-6 / EN 60068-2-27, refer also to
Installation instructions for enhanced mechanical load capacity [}35]
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Installation position variable
Pluggable wiring for all KSxxxx terminals
Protection class IP20
Approvals
CE, cULus, ATEX [}41], GL
