Product overview
KL1xxx26 Version: 1.0.0
Eight-channel, digital input terminals, 24 V
DC
The digital input terminals KL1408 and KL1418 (positive switching) and KL1488 and KL1498 (negative
switching) acquire the binary control signals from the process level and transmit them, in an electrically
isolated form, to the higher-level automation unit. The Bus Terminals each contain eight channels, whose
signal states are displayed by LEDs. They are particularly suitable for space-saving use in control cabinets.
By using the single-conductor connection technique a multi-channel sensor can be connected in the smallest
space with a minimum amount of wiring. The power contacts are looped through. For the KL1408 and
KL1418 Bus Terminals, the reference ground for all inputs is the 0V power contact. For the KL1488 and
KL1498 Bus Terminals, the reference point for all inputs is the 24V power contact. These versions have
input filters with different speeds.
2.6.1 KL1408, KL1418, KL1488, KL1498 – Technical data
Technical data KL1408, KS1408 KL1418, KS1418 KL1488, KS1488 KL1498, KS1498
Connection technology 1-wire
Number of inputs 8
Nominal voltage 24V
DC
(-15%/+20%)
Signal voltage ‘0’ -3V to 5V (EN 61131-2, type 1) 18V … 30V
Signal voltage ‘1’ 15V to 30V (EN 61131-2, type 1) 0V … 7V
Signal current '0' 0 to 1.5mA 0 to 1.5mA - -
Signal current '1' 2.0 to 2.5mA 2.0 to 2.5mA typ. 3mA typ. 3mA
Input filter 3ms 0.2ms 3ms 0.2ms
Current consumption from K-bus typically 5mA
Electrical isolation 500V (K-bus / field voltage)
Bit width in process image 8 input bits
Configuration no address or configuration settings required
Dimensions (W x H x D) 15mmx100mmx70mm (connected width 12mm)
Weight approx. 55g
Permissible ambient temperature
during operation
-25°C ... +60°C
(extended temperature range)
0°C ... +55°C
Permissible ambient temperature
during storage
-40°C ... +85°C -25°C ... +85°C
Permissible relative humidity 95%, no condensation
Vibration / shock resistance according to EN 60068-2-6 / EN 60068-2-27, refer also to
Installation instructions for enhanced mechanical load capacity [}35]
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Installation position variable
Protection class IP20
Pluggable wiring for all KSxxxx terminals
Approvals
CE, cULus, ATEX [}41], GL CE, cULus, ATEX [}41]
