2.6.3 KL1488, KL1498 - LEDs and connection
Fig.21: KL1488
KL1488, KL1498 - LEDs
LED Color Meaning
Signal LED 1 - 8 green off Signal voltage "0" (18V ... 30V)
on Signal voltage "1" (0V ... 7V)
KL1488, KL1498 - Connection
Terminal point Description
Name No.
Input1 1 Input 1
Input3 2 Input3
Input5 3 Input5
Input7 4 Input 7
Input2 5 Input2
Input4 6 Input4
Input6 7 Input6
Input8 8 Input8
