Beckhoff KL2791 Series User Manual

Product overview
KL279110 Version: 2.0.0
2.3 Technical data
Technical data KL2791-0000, KS2791-0000,
KL2791-0011, KS2791-0011
KL2791-1200
Mains voltage 230V
AC
120V
AC
Power rating 200VA (W), max. 0,9A 100VA (W), max.
0,85A
Load types Single-phase AC motors
Types of control Full-wave control, mixed control
Resolution 1%
Leakage current (OFF state) < 1mA
Electrical isolation 500V (K-bus /field voltage), 3750V
AC
(1min.)
Power supply for the electronics via the K-bus
Current consumption from K-bus typically 95mA
Bit width in the input process image 1 x 16bit data, 1 x 8bit status
Bit width in the output process image 1 x 16bit data, 1 x 8bit control
Configuration via the Bus Coupler or the controller
Weight approx. 60g
Permissible ambient temperature range
during operation
0°C ... + 55°C
Permissible ambient temperature range
during storage
-25°C ... + 85°C
Permissible relative air humidity 95%, no condensation
Dimensions (W x H x D) approx. 15mmx100mmx70mm (width aligned: 12mm)
Mounting on 35mm mounting rail conforms to EN60715
Vibration/shock resistance conforms to EN60068-2-6/ EN60068-2-27
EMC immunity/emission conforms to EN61000-6-2/ EN61000-6-4
Protection class IP20
Installation position variable
Pluggable wiring for all KSxxxx terminals
Approval CE
