Configuration Software KS2000
KL279128 Version: 2.0.0
5.4 Settings
The dialog mask for the parameterization of the KL2791 can be found under Settings.
Fig.18: Settings via KS2000
Operation mode
Watchdog timer active (R32.2 [
}
35])
Here you can deactivate the watchdog (default: active).
User scaling active (R32.0 [
}
35])
Here you can activate user scaling (default: inactive).
Register values
User offset (R33 [
}
36])
You can specify the offset for the user-scaling here (default: 0).
User gain (R34 [
}
36])
Here you can specify the user scaling gain (default: 1).
Timeout(R36 [
}
36])
Here you can specify the timeout time for detecting a fieldbus error (default: 100ms).
Control value for timeout (On) (R37 [
}
36])
Here you can specify the control value for a timeout at which the load was switched on when it occurred
(default: 50%).
