Configuration Software KS2000
KL279130 Version: 2.0.0
5.5 Process data
The Status byte (Status), the Control byte (Ctrl) and the process data (Data) are displayed in a tree structure
under ProcData.
Fig.19: ProcData
The reading glasses mark the data that are currently graphically displayed in the History field.
Fig.20: History field
The current input values are displayed numerically in the Value field.
Fig.21: Value field
Output values can be modified through direct input or by means of the fader control.
Fig.22: Value field
