Only needed after the module's assembly (usually only at the factory or by DIYers) or after some
critical components have been replaced.
The more precise is your voltage source the more precise the calibration will be. A +/-0.005V
tolerance voltage source is recommended for this operation.
A wrong calibration will disrupt the module's functionality. For example, an uncalibrated control
can cease functioning entirely, or the V/OCT In will be erratic and/or out of range.
1. Place both the PITCH knob and the VARISPEED knob in the middle (At 12:00), this allows
for calibrating the center point of these two potentiometers
2. Power the module while holding the [MOD AMT + SHIFT] buttons at the same time. The
[RECORD] button should light up red indicating you are in Calibration Mode. This
operation should be done With 0,0 volts (or nothing connected) at the V/OCT IN.
3. Plug 2.00 Volts into V/OCT IN and push the [RECORD] button. Now [SHIFT] button will
light up red.
4. Plug 5.00 Volts into V/OCT IN and push the [SHIFT] button. Now [RANDOM] button will
light up red.
5. Plug 8.00 Volts into V/OCT IN and push the [RANDOM] button. Now [MOD AMT] button
will light up green.
6. Move all manual controls to the minimum position, this is all pots counter-clockwise and
all faders down.
7. Move all manual controls to the maximum position, this is all pots clockwise and all
faders up.
8. Push the [MOD AMT] button to exit calibration mode.
