Modifying a distillation program
With the S 5, you can define 99 different distillation
programs. This allows you to define the appropriate
conditions and the appropriate quantities of reagents for
different analyses and different sample concentration
ranges.
The 100th programm, program no. 00, is a test program
to check the steam delivery rate of the device.
When defining a program, make a note of its purpose
and the settings you made.
Turn the operating control knob clockwise or counter-
clockwise until the menu item Program is highlighted.
Then press the knob once. You will now see the follow-
ing display:
You can now select which of the 99 programs of the S 5
you wish to enter or modify. Simply turn the operating
control knob until Prog.Number appears in green on a
black background. If you now press the knob once, you
will be able to dial to another number. Turning the knob
clockwise advances the display to the higher numbers,
while turning counterclockwise brings you to the lower
numbers. At both ends of the number range, continued
turning of the knob will bring you to the other end of the
range, specifically
turning clockwise beyond 99 will bring you
back to 00
turning counterclockwise from 00 will bring you
to 99.
By pressing on the operating control knob you will then
enter the programming options of the selected program
number.
If you are working with the S 5 for the first time, then
leave the program number selection on 01.
Pump delivery rates depend on the position of the
chemical vessels (desk or floor) and the length of
hose lines.
By turning the operating control knob and pressing,
select the option ==>>.
You will now see the following menu displayed:
NaOH
3.0
Dist.Time
060
Dil. H2O
3.0
==>><<== back
Prog.Number 01
Read the menu items as follows:
Prog.Number 01 You can modify the settings of pro-
gram no. 01
DIL.H
2
O
Delivery time for dilution water in
seconds. Possible entry values
range from 0.0 sec to 99.9 sec.
The factory default setting is
3.0 sec.
Delivery of the pump approx.
16 ml/sec.
80 ml/5 sec
965 ml/min
NaOH Delivery time for sodium hydro-
xide in seconds. Possible entry
values range from 0.0 sec to 99.9
sec. The factory default setting is
3.0 sec.
Delivery of the pump approx.
10 ml/sec.
51 ml/5 sec
610 ml/min
Dist.Time Distillation time in seconds. Possible
entry values range from 0 sec to 999
sec. The factory default setting is
300 sec.
<<== back
==>> further
If you wish to change an entry, simply turn the operat-
ing control knob to highlight the value of interest and
press the knob to access the entry value. Then dial the
desired value by turning the operating control knob and
enter it in memory storage by pressing the knob again.
Once all entry values have been entered according to
your wishes, select ==>> and press the operating con-
trol knob to bring up the following program menu.
Power
80%
DrainSample 010
Reac.time
010
Prog.Number 01
==>><<== back
